Hot Sale Multi-Refrirants Gas Leak Detector Halon Freon Testing Equipment for Refrirant Leak Detection

Hot Sale Multi-Refrirants Gas Leak Detector Halon Freon Testing Equipment for Refrirant Leak Detection

FOB Reference Price: Get Latest Price

≥10 Pieces

US $19

≥100 Pieces

US $16

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: RETEKOOL

Model Number:: LD, CPU, HLD. WJL

Product name:: HALOGEN LEAK DETECTOR

Application:: refrigerant leak detector

Usage:: Testing Instrument

Brand:: customized

Model:: Coustomization

Power supply:: Battery

Color:: Customer Required

Quick Details

Warranty:: 1 Year

Power:: Electronic

Place of Origin:: Zhejiang, China

Brand Name:: RETEKOOL

Model Number:: LD, CPU, HLD. WJL

Product name:: HALOGEN LEAK DETECTOR

Application:: refrigerant leak detector

Usage:: Testing Instrument

Brand:: customized

Model:: Coustomization

Power supply:: Battery

Color:: Customer Required

Leak Detector

High Sensitivity Handheld Refrigerant Infrared Leak Detector
ILD-200 is a handheld refrigerant leak detector that utilizes a long-life infrared sensor in a low-cost package to effectively pinpoint leaks of CFC, HFC, HCFC and HFO refrigerants. Ready for use in 30 seconds and with 8 hours of battery life in a single charge, ILD-200 is a tryly preferred tool.

The detector is a specially designed halogen detection device with higher cost performance.
With multiple functions,it is easy to operate,reliable in performance and compact in size.It can effectively pinpoint leaks
ofCFC,HFC,HCFC and HFO refrigerants. Ready for use in 30 seconds and w ith 8 hours of battery life in a single charge,ILD-100 is
truly preferred tool.

TECHINICAL PARAMETERS

* Sensitivity levels:Per SAE J2791
* High:0.1 oz/yr(4g/yr)
* Medium:0.25 oz/yr(7g/yr)
* High:0.5 oz/yr(14g/yr)
* Response time:less than1s
* warm-up time: 30 seconds; automatic calibration
* Automatic indicate of 1 hour run time in low battery
* operating temperature: 0°C-50 °C at 75%RH
* Operates continuously 8 hours; auto OFF after 10 minutes of inactivity
* Approvals:SAE J1627,SAE J2791,SAE J2913, CE(pending);EN 14624

Model	Warm-up time(s)	Response time(s)	Proble length(cm)	Screen (innch)	Product Size (cm)
LD-200	30	＜3	40	2.8	2084
LD-300	10	＜3	40	2.8	2084
LD-CO2	30	＜3	40	2.8	2084
CPU-C	6	＜3
HLD-100+	6	＜3
WJL-6000		＜3

Applications

It will respond to all halogenated (contains Chlorine of Fluorine) refrigerants. This includes, but is not limited to:
CFCs e.g.R12, R11,R500,R503 etc. HCFCs e.g. R22,R123, R124,R502 etc. HFCs e.g. R134a, R404s, R125 etc.
Blends such asAZ-50. HP62. MP39 etc.
Detect Ethylene Oxide gas leaks in hospital sterilizing equipment (it will detect the halogenated carrier gas).
Detect SF-6 in high voltage circuit breakers.
Detect most gases that contain chlorine, fluorine and bromine (halogen gases). Detect cleaning agents used in dry cleaning
applications
such as per chloroethylene. Detect halogen gases in fire-extinguishing system.
