*Conventional frame
*Boost bearing capability and prolong service life
*Serrated-clip design tensile strength
*Seal-lip design glue injection
*Silver or black frames are optional
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25years
-
Brand Name:
-
Goosun, Goosun
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722 x 1134 x 30mm
-
Color:
-
Black
-
No. of Cells:
-
108
-
Weight:
-
21.1kg
-
Glass:
-
3.2mm
-
Cable:
-
4mm2
-
Product name:
-
Sola Panel
-
Back Plate:
-
Aging resistance film
-
Connector:
-
Compatible Connector
-
Certificate:
-
ISO9001:2015 QMS
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, Bifacial, Double-glass, All Black, MWT
-
Panel Efficiency:
-
21%
-
Warranty:
-
25years
-
Brand Name:
-
Goosun, Goosun
-
Place of Origin:
-
Anhui, China
-
Panel Dimensions:
-
1722 x 1134 x 30mm
-
Color:
-
Black
-
No. of Cells:
-
108
-
Weight:
-
21.1kg
-
Glass:
-
3.2mm
-
Cable:
-
4mm2
-
Product name:
-
Sola Panel
-
Back Plate:
-
Aging resistance film
-
Connector:
-
Compatible Connector
-
Certificate:
-
ISO9001:2015 QMS
Product Introduction
Structure Parameter
*High Anti-PID resistant *Low breakage rate
*High module efficiency up to 20%
*High salt mist and ammonia resistance
*Easy for rooftop installation
*High module efficiency up to 20%
*High salt mist and ammonia resistance
*Easy for rooftop installation
Frame
Junction Box
*Long service life
*Heat dissipation
*IP68 protection level
*Conventional standalone edition and engineering custom edition
*Quality diode ensures module running safety
*Heat dissipation
*IP68 protection level
*Conventional standalone edition and engineering custom edition
*Quality diode ensures module running safety
Electrical Property Parameter
|
ELECTRICAL PARAMETERS
|
|
|
|
|
||||
|
Type
|
GC-410-45MDH
|
GC540-72MDH
|
GC545-72MDH
|
GC550-72MDH
|
||||
|
Conditions
|
STC NOCT
|
STC NOCT
|
STC NOCT
|
STC NOCT
|
||||
|
Rated Maximum Power(Pmax) [W]
|
410 309
|
540 409
|
545 412
|
550 416
|
||||
|
Open Circuit Voltage(Voc) [V]
|
49.74 47.16
|
50.04 47.63
|
50.18 47.87
|
50.32 48.10
|
||||
|
Maximum Power Voltage(Vmp) [V]
|
31.59 29.20
|
41.96 39.44
|
42.12 39.67
|
42.28 39.90
|
||||
|
Short Circuit Current(lsc) [A]
|
11.88 11.16
|
13.76 10.99
|
13.83 11.03
|
13.90 11.07
|
||||
|
Maximum Power Current(lmp) (A]
|
12.98 10.69
|
12.87 10.37
|
12.94 10.41
|
13.01 10.45
|
||||
|
Module Efficiency [%]
|
21%
|
20.89%
|
21.09%
|
21.28%
|
||||
|
Power Tolerance
|
0~+5W
|
|
|
|
||||
|
Temperature Coefficient of Isc(α_jsc) +0.045%/°C
|
|
|
|
|
||||
|
Temperature Coefficient of Voc(β_Voc) -0.275%/°C
|
|
|
|
|
||||
|
Temperature Coefficient of Pmax(γ_Pmp) -0.350%/°C
|
|
|
|
|
||||
|
STC（Standard Testing Conditions）：Irradiance 1000W/㎡,Cell Temperature 25℃.Spectra at AM1.5
NOCT(Nominal Operating Cell Temperature)：Irradiance 800W/㎡,Ambient Temperature 20℃，
Spectra at AM1.5 Wind at 1m/s
|
|
|
|
|
||||
|
OPERATING CONDITION
|
|
|
|
Maximum System Voltage
|
1000V/1500V DC(IEC)
|
|
|
Operating Temperature
|
•40°C~+85°C
|
|
|
Maximum Series Fuse
|
25A
|
|
|
Maximum Static Load,Front
|
5400Pa
|
|
|
Maximum Static Load,Back
|
2400Pa
|
|
|
NOCT
|
45±2°C
|
|
|
Safety Class
|
Glass Ⅱ
|
|
|
Fire Performance
|
UL Type 1
|
|
Our Company
Exhibition
Project Cases
Packing & Delivery
We promise:
100% product quality protection
100% on-time shipment protection
100% payment protection for your covered amount
100% product quality protection
100% on-time shipment protection
100% payment protection for your covered amount
Related Products
Payment
|
Payment Term
|
T/T
|
EXW
|
30% T/T in advance, paid the balance before shipment
|
|
|||
|
|
|
FOB
|
|
|
|||
|
|
|
CFR/CNF
|
30% T/T in advance, paid the balance against copy of B/L
|
|
|||
|
|
|
CIF
|
|
|
|||
|
|
L/C
|
L/C amount above 50,000 usd, we can accept L/C at sight
|
|
|
|||
|
|
West Union
|
Amount lower than 5000usd |
|
|
|||
|
Delivery Time
|
7~10days after receiving payment for one container
|
|
|
|
|||
|
|
|
|
|
|
|||
FAQ
Q1 :Are you a manufacturer or trading company ?
A1：We are a manufacturer, the factory with warehouse covers an area of more than 33,000 square meters.
Q2:What products can you offer ?
A2. Our products include the whole solar PV system covering residential, commericial and industrial level.
we also supply important components, such as solar panels, solar inverters, combined box, solar battery,
mounting bracket, PV cables, etc.
Q3: What certification do you have ?
A3: TUV/CE/ROHS/ISO report，etc.
Q4: What’s MOQ of Solar Panel ?
A: 1pallet. 31pcs/pallet
Q5:what services can we provide ?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,DDP,DDU；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
