Quick Details
-
Place of Origin:
-
Guangdong, China
-
PoE Ports:
-
8*10/100Mbps POE Ports
-
Uplink Ports:
-
2*10/100/1000Mbps Uplink Ports
-
Dimensions (W x D x H):
-
220*160*40mm
-
Weight:
-
1KG/pcs
-
MOQ:
-
2 Pcs
-
Package:
-
Carton
-
PoE Standard:
-
IEEE 802.3af/at
-
Power:
-
AC110-240V/50-60Hz
-
Data PIN:
-
12+36-/45+78-
-
Casing:
-
Metal
Quick Details
-
Transmission Rate:
-
10/100Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Model Number:
-
PIN-POE-8POE2GE
-
Place of Origin:
-
Guangdong, China
-
PoE Ports:
-
8*10/100Mbps POE Ports
-
Uplink Ports:
-
2*10/100/1000Mbps Uplink Ports
-
Dimensions (W x D x H):
-
220*160*40mm
-
Weight:
-
1KG/pcs
-
MOQ:
-
2 Pcs
-
Package:
-
Carton
-
PoE Standard:
-
IEEE 802.3af/at
-
Power:
-
AC110-240V/50-60Hz
-
Data PIN:
-
12+36-/45+78-
-
Casing:
-
Metal
Product Description
Power over Ethernet (PoE) is technology that passes electric power and data over twisted-pair ethernet cable to wireless access points,IP cameras. It enables one RJ45 patch cable to provide both a data connection and electric power to connected edge devices instead of having a separate cable for each, Save cabling costs.
Specification
|
Max Transmission Distance
|
250 meter
|
|
Casing
|
Metal
|
|
Network Cable
|
Cat5 or more
|
|
POE Standard
|
IEEE 802.3af, IEEE 802.3at
|
|
PoE Output Power
|
15.4W/30W
|
|
Input
|
110-240V,50-60 Hz
|
|
Output
|
48V
|
|
Dimensions
|
220*160*40mm(86.61"*62.99"*15.75")
|
|
Operating temperature
|
0-50℃(32-131℉)
|
|
Operating humidity
|
90% maximum relative humidity, non-condensing
|
|
Lightning Protection Level
|
Second Level Lightning Protection
|
|
Applicable Environment
|
Monitoring System Wireless Communication Smart Home
|
|
Fan
|
No Fan, Natural Heat Dissipation
|
|
Installation Method
|
Desktop
|
Packing & Delivery
Packaging Details
: Box or carton
Port
: Shenzhen
Lead time
:
Quantity
(pieces)
1 - 100 >100
Lead time (days) 7 To be negotiated
