Quick Details
-
Engine Brand:
-
Kubota
-
Travel Speed:
-
0~8 km/h
-
Place of Origin:
-
SHN
-
Brand Name:
-
SDBM
-
Dimension(L*W*H):
-
2255*1050*1770
-
Drum diameter:
-
560 mm
-
Brand:
-
SDBM
-
Product name:
-
BM2500
-
Drive mode:
-
Variable plunger pump infinitely variable speed
-
Engine:
-
CHANGCHAI
-
Engine Model:
-
3M78
-
Color:
-
yellow
-
Vibrate frequency:
-
65hz
-
Drive Type:
-
hydraulic motor
-
Steel Wheel Size:
-
900*630 mm
-
Operating weight:
-
2 Ton
Quick Details
-
Type:
-
Vibratory Roller
-
Power:
-
18.6 kW
-
Weight:
-
2 ton
-
Engine Brand:
-
Kubota
-
Travel Speed:
-
0~8 km/h
-
Place of Origin:
-
SHN
-
Brand Name:
-
SDBM
-
Dimension(L*W*H):
-
2255*1050*1770
-
Drum diameter:
-
560 mm
-
Brand:
-
SDBM
-
Product name:
-
BM2500
-
Drive mode:
-
Variable plunger pump infinitely variable speed
-
Engine:
-
CHANGCHAI
-
Engine Model:
-
3M78
-
Color:
-
yellow
-
Vibrate frequency:
-
65hz
-
Drive Type:
-
hydraulic motor
-
Steel Wheel Size:
-
900*630 mm
-
Operating weight:
-
2 Ton
Application
Product Description
Specification
|
Model
|
BM50
|
|
|
|||
|
WEIGHT
|
|
|
|
|||
|
Operating Weight
|
540kg
|
|
|
|||
|
Static Linear Load
|
45n/cm
|
|
|
|||
|
DIMENSION
|
|
|
|
|||
|
Working Width
|
780mm
|
|
|
|||
|
Overall Length
|
2480mm
|
|
|
|||
|
Overall Height
|
1820mm
|
|
|
|||
|
Packing Size
|
1600*850*1900mm
|
|
|
|||
|
Steel Wheel Width
|
600mm
|
|
|
|||
|
Steel Wheel Diameter
|
426mm
|
|
|
|||
|
Start Up
|
Recoil hand pull electric start
|
|
|
|||
|
DRIVE
|
|
|
|
|||
|
Engine Brand
|
HONDA
|
Changchai/Changfa
|
Changchai
|
|||
|
Engine Model
|
GX270
|
178F
|
RD180
|
|||
|
Engine Type
|
Gasoline, four stroke
|
Diesel, four stroke
|
Diesel,
water cooled |
|||
|
Number Of Cylinder
|
1
|
|
|
|||
|
Output Power
|
6.7kw
|
4.4kw
|
5.7kw
|
|||
|
Rotating Speed
|
3600rpm
|
3600rpm
|
2600rpm
|
|||
|
WALKING CHARACTERISTICS
|
|
|
|
|||
|
Speed
|
0-3.8km/h
|
|
|
|||
|
Grade Ability
|
30%
|
|
|
|||
|
BRAKES
|
|
|
|
|||
|
Walking Way
|
Two-way hydraulic, chain transmission
|
|
|
|||
|
EXCITING SYSTEM
|
|
|
|
|||
|
Vibrating Drum
|
Front+Rear
|
|
|
|||
|
Vibrating Frequency
|
70hz
|
|
|
|||
|
Vibrating Amplitude
|
0.6mm
|
|
|
|||
|
Exciting Force
|
20kn
|
|
|
|||
|
Model
|
BM2500
|
|
|
WEIGHT
|
|
|
|
Operating weight
|
2000kg
|
|
|
Static line load
|
110/105 n/cm
|
|
|
DIMENSIONS
|
|
|
|
Working width
|
1050mm
|
|
|
Overall length
|
2255mm
|
|
|
Overall height with ROPS
|
2445mm
|
|
|
Turning radius(inner/outer)
|
2955/4005mm
|
|
|
Drum width
|
900mm
|
|
|
Drum diameter
|
630mm
|
|
|
Wheel base
|
1565mm
|
|
|
DRIVE
|
|
|
|
Engine
|
Changchai 3M78/ Yanmar 3TNV76/ Kubota D1105
|
|
|
Type
|
Three cylinder, water-cooled, four-stroke, diesel engine
|
|
|
Output power
|
18.6kw
|
|
|
Rated speed
|
3200rpm
|
|
|
Electric equipment
|
12V
|
|
|
Drive mode
|
Variable displacement piston pump with infinitely variable speed, two-wheel drive motor in parallel/series
|
|
|
Walking speed
|
0-8km/h
|
|
|
Climbing ability (vibration on/off)
|
30%/ 35%
|
|
|
BRAKES
|
|
|
|
Working brake
|
Variable displacement pump
|
|
|
STEERING
|
|
|
|
Steering method
|
Hydraulic Cylinder, Articulated Steering
|
|
|
Steering system
|
Swing articulated
|
|
|
EXCITING SYSTEM
|
|
|
|
Vibration drum
|
Front/ front + rear
|
|
|
Driving form
|
Hydraulic motor
|
|
|
Vibration frequency
|
65hz
|
|
|
Amplitude
|
0.5mm
|
|
|
Exciting force
|
35kn/ 2*35 kn
|
|
|
SPRINKLER SYSTEM
|
|
|
|
Sprinkling type
|
intermittent pressure spray
|
|
|
CAPACITY
|
|
|
|
Hydraulic oil tank
|
45L
|
|
|
Fuel tank
|
36L
|
|
|
Water tank
|
140L
|
|
Product display
Packing & Delivery
Our vibratory road roller compactor can be packed as following.
1. steel frame
2,. plywood case
3. as customers' request
