1) Center conductor: TC, BC and CCS available, CCA;
2) Al-foil: Non-bonded Al-foil, bonded Al-foil, double bonded Al-foil, and double non-bonded Al-foil and Messenger are available;
3) Braiding wire: AL, BC and TC available;
4) Braiding wire diameter: 0.10, 0.12, 0.13, 0.14, 0.15, 0.16mm available;
5) Braiding net: 32, 48, 64, 72, 80, 96, 120, 128, 144 and more available;
6) Braiding coverage: Between 30- 97% available;
7) With 75 ° PVC jacket of Flame retardant or UV available.
- Product Details
- {{item.text}}
Quick Details
-
Application:
-
CCTV
-
Color:
-
Customized
-
Certification:
-
CE/ROHS/ISO9001
-
Shield:
-
Al Foil+braiding
-
Insulation:
-
SPE FPE
-
Length:
-
100m/200m/300m/customized
-
Conductor Material:
-
99.99% Bare Copper/CCA/CCS
-
Jacket:
-
PVC LSZH PE
-
Package:
-
100m PE Film
Quick Details
-
Brand Name:
-
SZADP/OEM
-
Model Number:
-
RG59
-
Place of Origin:
-
Guangdong, China
-
Application:
-
CCTV
-
Color:
-
Customized
-
Certification:
-
CE/ROHS/ISO9001
-
Shield:
-
Al Foil+braiding
-
Insulation:
-
SPE FPE
-
Length:
-
100m/200m/300m/customized
-
Conductor Material:
-
99.99% Bare Copper/CCA/CCS
-
Jacket:
-
PVC LSZH PE
-
Package:
-
100m PE Film
Product Details
Cable Data
|
Construction
|
|
|
|
Center Conductor
|
0.81mm+0.01mm Solid Copper/Copper Clad Steel(CCS)
|
|
|
Dielectric
|
3.66mm+0.05mmFoam PE
|
|
|
Shield
|
Bonded Al Foil / Unbonded Al Foil/copper foil
|
|
|
Braid Coverage
|
40%-97% Al Alloy / Copper /Copper Clad Al(CCA)
|
|
|
Jacket
|
6.0+0.1mm PVC/PE
|
|
|
Jelly/APD
|
Per Customers' request
|
|
|
2c power cable conductor
|
2x7x0.38mm Bare copper/copper clad Al(CCA)
|
|
|
2c power cable Dielectric
|
2X1.8mm PE Insulation
|
|
|
power cable Jacket
|
5.2mm PVC
|
|
