Sand Casting Grey Iron Flywheel

Pump elbow gray iron castings / Sand Casting Grey Iron Flywheel

1. About us

We are a professional foundry plant with more than 20years of history, we provide you high quality gray iron castings and high quality ductile iron castings with automatic static pressure molding casting line.

2. main specific

3. main products

We provide customized high quality gray iron castings and ductile iron castings for automobile, agricultural machinery, engineering machinery, rail transit, wind power, oil and related machinery and equipment manufacturers. The company has advanced automatic casting line and complete testing equipment, to meet the needs of customers for strength, accuracy, weight and appearance, the products have been widely praised by customers.

Differential housing for commercial vehicles

Hubcap,Differential housing,Flywheel for agricultural machinery,Brake discs for commercial vehicles,Differential housing for car,Cabinet,Wind power housing,Flywheel housing,Wind power nut,Flange,Engine flywheel housing,Stator bracket,Speedometer housing,Differential housing blank,Poor Shell,Rail Clamp ,Butterfly valve,Valve housing,Holder,Pedestal-shell,steam turbine casing,Stove Burner  ,Cast Iron Plate ,Manhole Cover ,Brake Drum ,Ductile Iron Belt Pulley ,Cast Iron Flywheel ,Boiler Ash Door

Stove Grate ,Tractor Gearbox ,Pump Body ,Cast Iron Brackets ,Gear Casting ,Flange Castings ,Cast Iron Axle Support ,Truck Castings ,Cast Iron Tractor Parts ,Cast Iron Stove Parts ,Boiler Soot Collector ,Butterfly Valve Body ,Cast Iron Manifold,Gray Iron Casting  ,Ductile Iron Casting,Cast Steel Casting,Tractor & Farming Cast Part,Truck & Trailer Casting Part,Stove & Boiler Casting Part,Seeding Knife Point Casting,Cast Iron Exhaust Manifold,Cradle Bracket of Cylinder,Pump & Valve Iron Casting

Pipe Part & Manhole Cover

OEM Iron Casting Parts for Tractor

4. Production strength

A professional foundry plant with more than forty years,provides professional customized services to customers worldwide.
The company has the world's leading green sand automatic casting molding line, equipped with complete testing equipment and a strong technical force team. Customers provide quality casting products.

5 . It also owns the whole inspection equipment and laboratory for chemistry and molding sand.

The company has advanced testing equipments and strict perfect quality management system, and we carry out strict testing on every product. The highly responsible intention of the inspector is dissolved in each component, and with advanced testing equipment and strict scientific management, every finished product produced can stand the selection of customers.

6.Our advantage:

001: Our foundry plant was founded in 1998, specializing in the sand casting industry for more than 20 years, capable of producing various grades of ductile iron castings and gray iron castings and cast iron radiator products.

002: The company passed the ISO9001 quality system certification, IATF16949 quality system certification, ISO14001 environmental management system certification.

003: Equipped with horizontal parting automatic static pressure molding line and automatic pouring machine, the hour production capacity is more than 6T, quick delivery and less waiting.

004: Equipped with Spike spectrometer, metallographic microscope, tensile testing machine, hardness testing machine, X-ray flaw detector and other professional testing equipment

005: Experience in overseas markets, the company's products are exported to more than 100 countries and regions around the world, to meet the technical standards and requirements of different regions.

7.What is sand casting?

Sand casting, also know as sand molded casting, is a metal casting process characterized by using sand as the mold material. Sand casting is most widely used to produce a wide variety of metal components with complex geometries, these parts can vary greatly in size and weight, ranging from a couple ounces to several tons.

Sand casting is relatively cheap and sufficiently refractory even for steel foundry use. Besides the sand, a suitable bonding agent (usually clay) is mixed with the sand. The mixture is usually moistened, typically with water, but sometimes with other substances, to develop the strength and plasticity of the clay and to make the aggregate suitable for molding. The term “sand casting” can also refer to a casting produced via the sand casting process. Sand casting are produced in specialized factories called foundries. Over 70% of all metal castings are produced via a sand casting process.

How does sand casting work?

The basic steps involved in making sand casting are:

1.Making pattern ( tooling)

Before starting sand casting, pattern making is the first step. The pattern is a full-sized model of finished product, should be slightly enlarged to account for thermal contraction or shrinkage and machining allowances in the casting.

Pattern Materials:

Metal---more expensive to make, but lasts much longer.

2.Making ssand core

Sand Core is a full-scale model of interior surfaces of casting, it is inserted into the mold cavity prior to pouring the molten metal flows and solidifies between the mold cavity and the core to form the casting ‘s external and internal surfaces. They are typically made of a sand mixture-sand combined with water and organic adhesives called binders-which is baked to form the core.This allows the cores to be strong yet collapsible, so they can be easily removed from the finished casting.

3.Sand Moulding

Moulding is the operation necessary to prepare a mold for receiving the metal. It consists of ramming sand around the pattern placed in support, or flask, removing the pattern, setting cores in place, and creating gating /feeding system to direct molten metal into the mold cavity created by the pattern, either by cutting it into the mold by hand or by including it on the pattern, which is most commonly used. In our foundry, majority of sand molds are created by automated moulding machine (Automatic static pressure molding line)

4.Melting, Pouring and Cooling

Melting is the preparation of the metal for casting, and its conversion from a solid to a liquid state in a furnace, namely molten metal, which is transferred in a ladle, then pouring it into sand mold. After the metal has solidified, breaking up the mold to remove casting.

5.Cleaning and Inspection

Cleaning includes all the operations required to remove the gates and risers that constitute the gating/feeding system and to remove the adhering sand, paring fins, and other foreign materials that are not part of finished casting. In the last stages of finishing, the surface of the casting is cleaned for improved appearance. In addition, at this point, the casting is inspected for defects and adherence to quality standards. This inspection may include non destructive testing to determine whether the part will adequately perform for its intended use.
