Quick Details
-
Table Size:
-
1.18m*0.87m *1.1m
-
Weight:
-
3750 kg
-
Marketing Type:
-
New Product 2023
-
Working height:
-
13.5m
-
Maximum platform height:
-
11.5m
-
Rated load:
-
215kg
-
Drive:
-
Two wheels
-
Total Weight:
-
3750kg
-
Maximum horizontal extension:
-
11.6m
-
Driving speed-closed state:
-
0-6km/h
-
Power source:
-
8*6V/420Ah Battery
-
Distance from the ground:
-
0.33m
-
Tail swing (platform retracted):
-
0m
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
China
-
Brand Name:
-
Beijun
-
Table Size:
-
1.18m*0.87m *1.1m
-
Weight:
-
3750 kg
-
Marketing Type:
-
New Product 2023
-
Working height:
-
13.5m
-
Maximum platform height:
-
11.5m
-
Rated load:
-
215kg
-
Drive:
-
Two wheels
-
Total Weight:
-
3750kg
-
Maximum horizontal extension:
-
11.6m
-
Driving speed-closed state:
-
0-6km/h
-
Power source:
-
8*6V/420Ah Battery
-
Distance from the ground:
-
0.33m
-
Tail swing (platform retracted):
-
0m
Product Description
Specification
|
Model
|
BJAP-12E
|
|
Size
|
Metric System
|
|
Working height
|
13.5m
|
|
Maximum platform height
|
11.5m
|
|
Maximum working distance
|
6.8m
|
|
Clearance height (maximum extension state)
|
5.7m
|
|
Platform size
|
1.18m×0.87m x 1.1m
|
|
Overall width
|
1.64m
|
|
Length of the whole machine
|
5.27m
|
|
Collection height
|
1.98m
|
|
Distance from the ground
|
0.12m
|
|
Performance
|
|
|
Maximum number of workers (indoor/outdoor)
|
2/1
|
|
Rated load
|
215kg
|
|
Driving speed-closed state
|
0-4km/h
|
|
Driving speed-lifting state
|
0-0.8km/h
|
|
Platform rotation angle
|
160°
|
|
Turning radius-inside
|
1.12m
|
|
Turning radius-outside
|
3.0m
|
|
Tail swing (the platform is raised)
|
0m
|
|
Tail swing (platform retracted)
|
0.75m
|
|
Control
|
Proportional control
|
|
Drive
|
Two wheels
|
|
Tires-Non-marking tires
|
22 x 9-16
|
|
Drive System
|
Direct drive AC
|
|
Power
|
|
|
Power source
|
8 x 6V/224Ah Battery
|
|
Total Weight
|
3750kg
|
