Quick Details
-
Brand Name:
-
WInvall
-
Standard or Nonstandard:
-
Standard
-
Control way::
-
ON/OFF or 3~Point
-
Actuator Shell::
-
PC+GF10
-
Actuator Base::
-
PC+GF10
-
Actuator Revolving Shaft:
-
POM
-
Certificate::
-
CE&ROHS
-
Type:
-
BALL VALVES
Quick Details
-
Port Size:
-
1/2'',3/4'',1''
-
Place of Origin:
-
Hunan, China
-
Model Number:
-
WRA-6302+W8BV3..
-
Brand Name:
-
WInvall
-
Standard or Nonstandard:
-
Standard
-
Control way::
-
ON/OFF or 3~Point
-
Actuator Shell::
-
PC+GF10
-
Actuator Base::
-
PC+GF10
-
Actuator Revolving Shaft:
-
POM
-
Certificate::
-
CE&ROHS
-
Type:
-
BALL VALVES
Description of Motorized Water Valve
Winner m otorized ball valve consists of on/off type or 3-point type actuator and W8BV… series ball valve , which have compact structure , stable operation , excellent capacity of water stoppage, large water flow rate, zero dirt block and low torque .
Application of Motorized Water Valve
HVAC system , heating system , Water treatment system , Industrial equipment
Ball Valve
|
Model No. |
Type |
Inner Dia. |
Inch |
Kvs(m3/h) |
Pmax(KPa) |
Ps(KPa) |
|
W8BV315 |
3-way |
12mm |
1/2 |
6.83 |
1000 |
1400 |
|
W8BV320 |
15mm |
3/4 |
8.6 |
1000 |
1400 |
|
|
W8BV325 |
20mm |
1 |
10 |
1000 |
1400 |
Actuator
|
Model No. |
Working Voltage |
Actuator type |
Output torque |
Consumption |
On/off time |
Valve body |
|
WRA-6302 |
24VAC±15% 50/60Hz |
3-point or on/off |
3.5N.m |
5W |
50Hz:16S 60Hz:12S |
W8BV315 W8BV320 W8BV325 |
