Quick Details
-
Specification:
-
CFM3/8"xM1/2", F1/2"xM3/8"
-
Length:
-
60/80/100/120/150/200cm
-
Thickness:
-
2.75mm
-
Standard:
-
ISO
Quick Details
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
as your demand
-
Model Number:
-
SGS
-
Specification:
-
CFM3/8"xM1/2", F1/2"xM3/8"
-
Length:
-
60/80/100/120/150/200cm
-
Thickness:
-
2.75mm
-
Standard:
-
ISO
PVC Gas Hose with Blue Strip
Dimension: CFM3/8 ”x M1/2 ” ,F1/2"xM3/8
Lenghts: 60/80/100/120/150/200CM
Applications: LPG,CNG
Max Working Temper ature: < 60℃
Max Working Pressure: 6Mpa;
Quality Certificates: ISO9001-2008;
Guarantee: 5 years;
Material and Dimensions of Hose Parts:
|
No. |
Name |
Material |
Dimension |
Qty |
Length |
|
1 |
T ube with blue strip |
Double Layer PVC |
8.5*14mm |
As Length |
100cm 120cm 150cm |
|
2 |
3/8 ” Female Nut |
Iron/brass-plated |
5/8 ” -18NF(19*20*10.1) |
1pc |
|
|
3 |
3/8 ” Core |
Iron/brass-plated |
8.7*5.5* 27.5 mm |
1pc |
|
|
4 |
3/8 ” X1/2 ” Male Nipple |
Iron/brass-plated |
1/2 ” NPT-14 to 5/8 ” -18NF |
1pc |
|
|
5 |
1/2 ” Male Nipple |
Iron/brass-plated |
1/2 ” NPT-14 |
1pc |
|
|
6 |
Sleeves |
Iron/brass-plated |
16.2*18.5*0.6mm |
2pcs |
Testing we do on Hoses:
1) Leakage Testing: Piece by piece, T ested under 10bar for 3 second, no leakage !
2) Tensile Testing: Sampling tested by hanging100KGS object for 5 minutes, no loose !
3) Burst Pressure Testing: Sampling t ested in burst machine, by increasing pressure to 50bar, no broken !
Terms and Conditions:
1) MOQ: total quantities no less than 5000pieces and the total amount no less than USD5000 each order;
2) Payment term: 30% deposit before production and the balance paid against copy of B/L;
3) Loading port: Yiwu, Ningbo or Shanghai port, China;
4) Delivery time: 35-40 days after deposit;
5) Price term: EXW, FOB, CNF or CIF
Our Services:
1) Put your logo on ours hose or packing.
2) Produce hoses as your drawings or samples.
