- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Zhejiang
-
Brand Name:
-
Runguan
-
Model Number:
-
RG-05
-
Product Name:
-
micro linear actuator
-
Voltage:
-
6V/12VDC
-
Load capacity:
-
188N=18kgs
-
Max speed:
-
150mm/s=6inch/s
-
Waterproof:
-
IP50
-
Limit switch:
-
yes
-
pipe material:
-
aluminum alloy
-
stroke:
-
10/17.5/21/30/50/100/150mm
-
noise:
-
less than 55dB
-
Certification:
-
CE
Quick Details
-
Speed(RPM):
-
customize
-
Continuous Current(A):
-
customize
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Zhejiang
-
Brand Name:
-
Runguan
-
Model Number:
-
RG-05
-
Product Name:
-
micro linear actuator
-
Voltage:
-
6V/12VDC
-
Load capacity:
-
188N=18kgs
-
Max speed:
-
150mm/s=6inch/s
-
Waterproof:
-
IP50
-
Limit switch:
-
yes
-
pipe material:
-
aluminum alloy
-
stroke:
-
10/17.5/21/30/50/100/150mm
-
noise:
-
less than 55dB
-
Certification:
-
CE
Advantages and applications
---
MOQ 1 piece
---
The prices are based on the stroke. Please ask the customer service before placing an order.
Linear motion actuators have stylish appearance, compact structure, small size, light weight, considerate low-noise telescopic operation, and have short-circuit protection, overload protection, overvoltage protection and waterproof design.
* 【Multiple Protections】： mini electric linear actuators have stylish appearance, compact structure, small size, light weight,considerate low-noise telescopic operation, and have short-circuit protection, overload protection, overvoltage protection and waterproof design.
* 【Precision Design】：micro linear actuator shell is made of high-quality plastic, and the telescopic rod part is made of aluminum alloy, which is not easy to rust and more durable. The intelligent machine lock design can be paused at any position. The built-in limit switch will automatically stop from the top to the bottom. Avoid motor idling.
* 【Easy To Install: 】：mini electric linear actuators are powered by 12VDC. Connect the positive and negative poles correctly and apply a voltage, and the linear actuator will extend; reverse the polarity and it will retract. Comes with a mounting bracket for easy installation.
* 【widely Used】：micro linear actuator are widely used in the automation of standard components and household items in automotive,aerospace, agriculture, manufacturing, solar, medical and robotics. Such as retractable awnings, adjustable beds, tables, chaise longues, skylights, curtain controls and lift integrated cooktops, etc.
* 【Precision Design】：micro linear actuator shell is made of high-quality plastic, and the telescopic rod part is made of aluminum alloy, which is not easy to rust and more durable. The intelligent machine lock design can be paused at any position. The built-in limit switch will automatically stop from the top to the bottom. Avoid motor idling.
* 【Easy To Install: 】：mini electric linear actuators are powered by 12VDC. Connect the positive and negative poles correctly and apply a voltage, and the linear actuator will extend; reverse the polarity and it will retract. Comes with a mounting bracket for easy installation.
* 【widely Used】：micro linear actuator are widely used in the automation of standard components and household items in automotive,aerospace, agriculture, manufacturing, solar, medical and robotics. Such as retractable awnings, adjustable beds, tables, chaise longues, skylights, curtain controls and lift integrated cooktops, etc.
Product Description
Specification
|
item
|
Electric linear actutor
|
|
Warranty
|
3months-1year
|
|
Place of Origin
|
Zhejiang
|
|
Max Speed
|
150mm/s=6inch/s
|
|
Model Number
|
RG-T18 Series
|
|
Inner pipe material
|
Aluminum alloy
|
|
Usage
|
Skylight Lifting bed Massage Chair Toy & robot Range hoods Agricultural irrigation
|
|
Speed(RPM)
|
custom
|
|
Continuous Current(A)
|
custom
|
|
Product Name
|
Economical Linear Actuator For Hospital Bed dental Chair
|
|
Voltage
|
6/12VDC
|
|
Max Load capacity
|
188N=18kgs
|
|
working frequency
|
The working frequency of the miniature linear actuator is 10%, the continuous expansion and contraction time shall not exceed 2
minutes, and the rest period shall be more than 18 minutes. (Power-on does not count, only the time when the push-pull tube is in motion) |
|
Noise
|
less than 55dB
|
Packing & Delivery
export standard carton; carton + pallet
