Quick Details
-
Model Number:
-
YB1203000-USB
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
About 307g
-
Electric Energy:
-
33.3 Wh
-
Voltage:
-
11.1V
-
Capacity:
-
3Ah
-
Dimension:
-
23*60*100mm
-
Connectors:
-
5.5*2.1mm DC jack+5.5*2.1mm DC plug
-
Battery cells:
-
A grade 18650 cells
-
Recharge cycle:
-
More than 500 times
-
Operating temperature:
-
-20 °C to 60 °C
-
Charge temperature:
-
-0 °C to 45 °C
-
Charge/Discha rge connecor:
-
DC5521 USB A
-
Max.Charge/ discharge current:
-
3V/12V 3A 5V 2A
Quick Details
-
Anode Material:
-
NCM
-
Application:
-
Consumer Electronics, CPAP Battery, LED Light Bar Products, CCTV Camera, LED Panel, Video, Speaker, Car DVR, Smart Phone
-
Brand Name:
-
TalentCell/YaBo
-
Model Number:
-
YB1203000-USB
-
Place of Origin:
-
Guangdong, China
-
Weight:
-
About 307g
-
Electric Energy:
-
33.3 Wh
-
Voltage:
-
11.1V
-
Capacity:
-
3Ah
-
Dimension:
-
23*60*100mm
-
Connectors:
-
5.5*2.1mm DC jack+5.5*2.1mm DC plug
-
Battery cells:
-
A grade 18650 cells
-
Recharge cycle:
-
More than 500 times
-
Operating temperature:
-
-20 °C to 60 °C
-
Charge temperature:
-
-0 °C to 45 °C
-
Charge/Discha rge connecor:
-
DC5521 USB A
-
Max.Charge/ discharge current:
-
3V/12V 3A 5V 2A
Products Description
|
Model
|
YB1203000-USB
|
|
Type
|
Li-ion battery with PCM
|
|
Nominal voltage
|
12 volt
|
|
Typical capacity
|
3000mah
|
|
Input
|
12.6 v
|
|
Out-put
|
12V 3A/ 5V 2A
|
|
Max continuous charge/discharge current
|
3A(adjustable)
|
|
Charger Included
|
0.5A charger:US plug/EU plug/UK plug
|
|
Connectors
|
5.5*2.1mm DC jack+5.5*2.1mm DC plug
|
|
Protection
|
12VPCM,over-charge/discharge protection, over-heat protection
|
|
Recharge cycle
|
More than 500 times
|
|
LED Indicator
|
Available
|
|
ON/OFF Switch
|
Available
|
|
Key word
|
12v battery with charger
|
|
Standard Charge Time
|
Around 3H
|
|
Dimension
|
23*55*100mm
|
|
Weight(approximate)
|
185g
|
|
Operating temperature
|
-20 °C to 60 °C
|
|
Charge temperature
|
-0 °C to 45 °C
|
|
Storage temperature
|
-20 °C to 45 °C
|
|
Operating humidity
|
5% to 90%,non-condensing
|
