Quick Details
-
Place of Origin:
-
Guangdong, China, Guzhen, Guangdong
-
Brand Name:
-
DOB
-
Min. Line Width:
-
\
-
Min. Line Spacing:
-
\
-
Surface Finishing:
-
polished
-
Board Size:
-
\
-
Warranty(Year):
-
2-Year
-
Color Temperature(CCT):
-
6500k
-
Input Voltage(V):
-
85-265V
-
LED chip:
-
2835
-
Lifespan (hours):
-
270
-
Working Time (hours):
-
50000
-
Input current:
-
120MA
-
Supply Ability:
-
10000 Bags per Month
-
Number of lamp beads:
-
40\50\60 hats
Quick Details
-
Base Material:
-
Aluminum
-
Board Thickness:
-
0.75mm
-
Model Number:
-
GFS
-
Place of Origin:
-
Guangdong, China, Guzhen, Guangdong
-
Brand Name:
-
DOB
-
Min. Line Width:
-
\
-
Min. Line Spacing:
-
\
-
Surface Finishing:
-
polished
-
Board Size:
-
\
-
Warranty(Year):
-
2-Year
-
Color Temperature(CCT):
-
6500k
-
Input Voltage(V):
-
85-265V
-
LED chip:
-
2835
-
Lifespan (hours):
-
270
-
Working Time (hours):
-
50000
-
Input current:
-
120MA
-
Supply Ability:
-
10000 Bags per Month
-
Number of lamp beads:
-
40\50\60 hats
Products Description
|
Specification
|
12w
|
16w
|
20w
|
26w
|
32w
|
40w
|
50w
|
60w
|
|||||||
|
actual power
|
9w
|
12w
|
15w
|
19w
|
24w
|
31w
|
38w
|
45w
|
|||||||
|
voltage range
|
85V-265V
|
|
|
|
|
|
|
|
|||||||
|
capacitance
|
3.3uF
|
4.7uF
|
4.7uF
|
6.8UF
|
10uF/400V 2.2uF 250V
|
12uF/400V 2.2uF250V
|
15uF/400V 2.2uF250V
|
15uF/400V 2.2uF250V
|
|||||||
|
Number of LEDs
|
12hạt
|
16hạt
|
20hạt
|
26hạt
|
32hạt
|
40hạt
|
50hạt
|
60hạt
|
|||||||
|
LED lamp bead power
|
1w
|
|
|
|
|
|
|
|
|||||||
|
LED lamp bead bracket
|
Equivalent Copper Bracket
|
|
|
|
|
|
|
|
|||||||
|
Extractive efficiency
|
75%
|
|
|
|
|
|
|
|
|||||||
|
Led Maximum Load Current
|
120MA
|
|
|
|
|
|
|
|
|||||||
|
Total lumens (lumen)
|
765LM
|
1020LM
|
1275LM
|
1615LM
|
2040LM
|
2638LM
|
3230LM
|
3825LM
|
|||||||
|
Lighting effect without hood
|
85LM/W
|
|
|
|
|
|
|
|
|||||||
|
Color change index
|
80Ra
|
|
|
|
|
|
|
|
|||||||
|
color temperature
|
6500k
|
|
|
|
|
|
|
|
|||||||
|
material
|
Aluminum plate
|
|
|
|
|
|
|
|
|||||||
|
size
|
￠35X37*0.8
|
￠41.5*42.5*0.8
|
￠47*47*1
|
|
￠59*62*1.0
|
￠74.3X70.6*1.0
|
|
|
|||||||
|
Lamp maximum temperature
|
120°C
|
|
|
|
|
|
|
|
|||||||
