Power Long Reach Chainsaw

Pole Chainsaw Features and Functions:

1. High-twig sawing refers to the high-level branch pruning saw, also known as lawn mower, mobile hoe, which is one of the commonly used gardening machines for ploughing trees in landscaping.
2. It is a kind of garden machinery with single operation and high difficulty. The main application areas are landscaping, courtyard maintenance, road cleaning, forest fire prevention, and crop harvesting.
3. Divided into electric and internal combustion by different power: Internal combustion power is divided into two-stroke and four-stroke gasoline engines. It is divided into soft shaft transmission and straight rod transmission by different transmission modes.

Instructions
1. Engine start
1.1 When starting, the choke should be opened when the vehicle is cold, and the choke should not be used when the vehicle is hot. At the same time, the manual pump is pressed more than 5 times.
1.2 Put the machine motor support and shackle on the ground, and stabilize it in a safe position. If necessary, place the shackle in a higher position, remove the chain protection device, and the chain should not touch the ground or other objects.
1.3 Select a safe position to stand firmly, press the machine to the ground with the left hand at the fan casing, the thumb is under the fan casing, do not step on the protection tube, and do not lie on the machine.
1.4 Slowly pull out the starting rope until it stops, and then pull it back quickly and forcefully.
1.5 If the carburetor is properly adjusted, the cutting tool chain cannot be rotated at the idle position.
1.6 When the load is empty, the throttle should be pulled to the idle speed or small throttle position to prevent the flying phenomenon; the throttle should be large when working.
1.7 When all the oil in the fuel tank is used up and refilled, the manual oil pump is pressed at least 5 times and then restarted.

2. Method of trimming branches
2.1 Cut the mouth first, then cut the mouth to prevent the saw.
2.2 Cut the branches below before cutting. Heavy or large branches are cut in sections.
2.3 When operating, hold the operating handle with your right hand, and naturally hold the left hand on the handle, and straighten your arm as far as possible. The angle between the machine and the ground should not exceed 60°, but the angle should not be too low, otherwise it is not easy to operate.
2.4 In order to avoid damage to the bark, the machine rebounds or the saw chain is clamped, when cutting the thick branches, first unload the load on the lower side, that is, cut an arc-shaped cut under the end of the guide.
2.5 If the diameter of the branch exceeds 10 cm, the pre-cut is first performed, and the unloading cut and the cut are made at about 20 to 30 cm at the desired cut, and then cut with a branch saw.

3. Use of chain saw
3.1 Always check the tension of the chain. When checking and adjusting, please turn off the engine and put on protective gloves. A suitable condition for tensioning is that the chain can be pulled by hand when the chain is hung in the lower part of the guide.
3.2 There must always be a little oil spill on the chain. The chain lubrication and the oil level of the oil tank must be checked before each work. Chains that are not lubricated must not work. If you work with a dry chain, the cutting device will be damaged.
3.3 Never use old oil. Old oil does not meet lubrication requirements and does not apply to chain lubrication.
3.4 If the oil level in the fuel tank does not decrease, it may be that the lubrication delivery has failed. Chain lubrication should be checked to check the oil circuit. A contaminated filter can also cause a poor supply of lubricant. The oil filter in the tank and pump connection piping should be cleaned or replaced.
3.5 After the replacement of the new chain, the saw chain takes 2 to 3 minutes of running-in time. Check the chain tension after running in and re-adjust if necessary. New chains require more tension than chains that have been used for some time. In the cold state, the saw chain must be attached to the lower part of the guide, but the saw chain can be moved by the hand on the upper guide. If necessary, tighten the chain. When the working temperature is reached, the saw chain expands slightly and the drive section at the lower part of the guide plate cannot escape from the chain slot, otherwise the chain will quit and the chain needs to be re-tensioned.
3.6 Chain must be relaxed after work. The chain will shrink when cooled, and a chain that is not relaxed can damage the crankshaft and bearings. If the chain is tensioned under working conditions, the chain will shrink when cooled, and too tight a chain will damage the crankshaft and bearings.
