Quick Details
-
Chip Material:
-
INGAN
-
Input Voltage(V):
-
AC100V-220V 50/60HZ to DC12V/4A
-
Product Weight（kg）:
-
3
-
Luminous Intensity:
-
100
-
Optical Attenuation(%):
-
1
-
Power Dissipation:
-
3
-
Viewing Angle(°):
-
135°
-
Color Temperature:
-
5000K
-
Operating Temperature(℃):
-
-10 - 50
-
Storage Temperature(℃):
-
-10 - 50
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Height-LED
-
Radiant Intensity(mW/Sr):
-
100
-
Application:
-
Optical Communication, Medical Consumables.etc
-
Keyword:
-
High Productivity
-
Control Style:
-
MCU+HIM
-
Cooling Method:
-
Fan cooling/Nature cooling
-
Package Type:
-
Carton
-
Certification:
-
CE RoHS
-
After-sales Services Provided:
-
Online Support
Quick Details
-
Warranty(Year):
-
1-Year
-
Support Dimmer:
-
Yes
-
Luminous Efficacy(lm/w):
-
100
-
Chip Material:
-
INGAN
-
Input Voltage(V):
-
AC100V-220V 50/60HZ to DC12V/4A
-
Product Weight（kg）:
-
3
-
Luminous Intensity:
-
100
-
Optical Attenuation(%):
-
1
-
Power Dissipation:
-
3
-
Viewing Angle(°):
-
135°
-
Color Temperature:
-
5000K
-
Operating Temperature(℃):
-
-10 - 50
-
Storage Temperature(℃):
-
-10 - 50
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Height-LED
-
Radiant Intensity(mW/Sr):
-
100
-
Application:
-
Optical Communication, Medical Consumables.etc
-
Keyword:
-
High Productivity
-
Control Style:
-
MCU+HIM
-
Cooling Method:
-
Fan cooling/Nature cooling
-
Package Type:
-
Carton
-
Certification:
-
CE RoHS
-
After-sales Services Provided:
-
Online Support
|
Product parameter
|
|
|
|
Model
|
HTLD-4II
|
|
|
Controller size
|
L168mm*W100mm*H145mm
|
|
|
Curing area
|
Φ3/Φ4/Φ6/Φ8/Φ10/Φ12/Φ15/Φ20(mm)
|
|
|
Wavelength
|
365/385/395/405nm (optional)
|
|
|
Connecting line length
|
2m/5m
|
|
|
|
395nm 405nm 3.5W/cm²
|
|
|
Lamp beads life
|
≥20000H
|
|
|
Cooling method
|
Fan cooling/natural cooling
|
|
|
Control style
|
MCU+HMI
|
|
|
Parameter setting
|
Key operation, foot switch, RS232 remote operation
|
|
|
Power adjustment
|
Digital dimming (1-100%)
|
|
|
Voltage
|
AC100-220V(50/60HZ) to DC12V/4A
|
|
|
Net weight
|
3KG
|
|
|
Total power consumption
|
20W
|
|
|
Ambient temperature
|
-10°C-50°C
|
|
|
Relative humidity
|
25%-80%RH
|
|
|
Diameter (mm)
|
|
Φ3
|
Φ4
|
Φ6
|
Φ8
|
Φ10
|
Φ12
|
Φ15
|
Φ20
|
|
|
Distance (mm)
|
|
10
|
10
|
15
|
15
|
20
|
20
|
35
|
25
|
|
|
optical intensity
(mw/cm²)
|
365nm
|
10400
|
12600
|
6200
|
4800
|
2500
|
2100
|
1900
|
800
|
|
|
|
385nm
|
9200
|
10100
|
5600
|
4200
|
2700
|
2700
|
1800
|
1200
|
|
|
|
395nm
|
14300
|
15100
|
8500
|
6100
|
3800
|
3800
|
2400
|
1000
|
|
|
|
405nm
|
15500
|
17400
|
10200
|
7300
|
4600
|
4800
|
3000
|
1000
|
|
FAQ
Q1: Why choose Height-LED UV LED curing system?
A: The team has over 10 years combined experience in UV LED curing industry and can meet the requirements of each client.
Q2: What's the application of Height-LED UV LED curing system ?
A: Height-LED UV LED curing system can be used for curing UV glue, UV ink, UV adhesive, UV paint, UV varnish and other UV sensitive materials.
Q3: What is the major advantages of UV LED curing system than other UV curing system?
A: Extra-long life, energy saving and environment friendly.
Q4: Which wavelength do I need?
A: It depends on your UV sensitive materials.
Q5: What's the emitting window do I need?
A: It depends on your product' S size that need to be cure.
Q6: What's the Peak Irradiance do I need?
A: It depends on your UV sensitive materials and your Production efficiency.
Q7:The common emitting window and Peak Irradiance can not meet my requirements?
A: Do not worry! Any sizes of emitting window and Peak Iadiance can be customized.
Q8: Where is your company located?
A: 2/F, Towel B, Sanhe international science and technology Building, Da Lang Road,Long Hua District, ShenZhen, Guang Dong Province, China.
Q9: What's the price?
A: Kindly make a request and tell us your curing area.
