Quick Details
-
Weight:
-
2600 KG
-
Model Number:
-
M954KQ
-
Engine Model:
-
V3800-DI-T
-
No. of cylinders:
-
4
-
engine power:
-
70.8kw
-
fuel tank capacity:
-
90L
-
Dimension(L*W*H):
-
4200*2120*2600mm
-
Min. Ground Clearance (mm):
-
490mm
-
After-sales Service Provided:
-
Video technical support
Quick Details
-
Rated Power (HP):
-
95HP
-
Brand Name:
-
kubota
-
Place of Origin:
-
Jiangsu, China
-
Weight:
-
2600 KG
-
Model Number:
-
M954KQ
-
Engine Model:
-
V3800-DI-T
-
No. of cylinders:
-
4
-
engine power:
-
70.8kw
-
fuel tank capacity:
-
90L
-
Dimension(L*W*H):
-
4200*2120*2600mm
-
Min. Ground Clearance (mm):
-
490mm
-
After-sales Service Provided:
-
Video technical support
Product Description
Specification
|
TYPE
|
|
|
|
Unit
|
M954K
|
M954KQ
|
|||
|
|
|
|
|
|
Fan type
|
Air conditioning type
|
|||
|
Dimensions
|
Structure type
|
|
|
|
4 wheel drive
|
|
|||
|
|
Dimensions
|
Length (front counterweight)
|
|
mm
|
4445
|
|
|||
|
|
|
Width (with post weight)
|
|
mm
|
2215
|
|
|||
|
|
|
Cab type
|
|
mm
|
2620
|
2695
|
|||
|
|
Tread
|
Front wheel
|
|
mm
|
16,601,760
|
|
|||
|
|
|
Rear wheel
|
|
mm
|
1,600,172,018,001,920
|
|
|||
|
|
Wheelbase
|
|
|
mm
|
2350
|
|
|||
|
|
Minimum ground clearance
|
|
|
mm
|
500（traction rod bracket）
|
|
|||
|
|
Minimum use of mass
|
|
|
kg
|
3245
|
3270
|
|||
|
|
Turn round radius
|
No side brake
|
|
m
|
4.5
|
|
|||
|
|
|
Unilateral brake
|
|
m
|
3.5
|
|
|||
|
|
Number of stalls
|
|
|
|
12F + 12R
|
|
|||
|
|
Power output shaft power
|
|
|
kW
|
60.2
|
|
|||
|
Engine
|
Model
|
|
|
|
V3800-DI-T-ET20
|
|
|||
|
|
Type
|
|
|
|
Vertical water cooled 4 - cylinder turbocharged diesel engine
|
|
|||
|
|
Number of cylinders
|
|
|
|
4
|
|
|||
|
|
Calibration speed
|
|
|
r/min
|
2600
|
|
|||
|
|
Calibration power (12h)
|
|
|
kW
|
70.8
|
|
|||
|
|
Battery specifications
|
|
|
|
12V,RC:160min,CCA 900A
|
|
|||
|
|
Fuel tank volume
|
|
|
L
|
105
|
|
|||
|
Walking steering brake system
|
Tire Specifications
|
Front Wheel
|
|
|
12.4-24
|
|
|||
|
|
|
Rear wheel
|
|
|
16.9-34
|
|
|||
|
|
Steering type
|
|
|
|
Independent oil, full hydraulic front wheel steering
|
|
|||
|
|
Driving brakes
|
|
|
|
Mechanical, wet, disc type
|
|
|||
|
|
Parking brake
|
|
|
|
Pedal lock type, handle type
|
|
|||
|
Transmission system
|
Clutch type
|
|
|
|
Single acting, dry, single plate
|
|
|||
|
Working equipment
|
Suspension Type
|
|
|
|
Ⅱ
|
|
|||
|
|
The maximum lifting force at 610 mm on the frame
|
|
|
Kn
|
18
|
|
|||
|
|
Traction device type
|
|
|
|
Bracket type (height adjustable) / traction rod type (optional)
|
|
|||
|
Power output
|
Type
|
|
|
|
Independence, 8 splines
|
|
|||
|
|
Speed
|
|
|
r / min
|
540/720
|
|
|||
|
Option
|
Hydraulic output valve
|
|
|
|
Group 2,Group 3
|
|
|||
|
|
High flower of paddy field
|
|
|
|
9.5-24/16.9-30
|
|
|||
