Quick Details
-
Brand Name:
-
BYOND
-
Model Number:
-
DSP5 Air
-
Model:
-
DSP5 ,DSP5 Pro,DSP5 Air
-
Max injection pressure:
-
within 250kPa
-
Power consumption:
-
50VA
-
Fuse:
-
T2A/250VAC
-
Equipment classification:
-
Class I, Type CF, Continuous operation
-
IP classification:
-
IP44
-
Screen Dimensions:
-
7" touchscreen
-
Dimensions:
-
384mm(L)*223mm(W)*231mm(H)
-
Gross weight:
-
4.6kg
-
Net weight:
-
3.6kg
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
BYOND
-
Model Number:
-
DSP5 Air
-
Model:
-
DSP5 ,DSP5 Pro,DSP5 Air
-
Max injection pressure:
-
within 250kPa
-
Power consumption:
-
50VA
-
Fuse:
-
T2A/250VAC
-
Equipment classification:
-
Class I, Type CF, Continuous operation
-
IP classification:
-
IP44
-
Screen Dimensions:
-
7" touchscreen
-
Dimensions:
-
384mm(L)*223mm(W)*231mm(H)
-
Gross weight:
-
4.6kg
-
Net weight:
-
3.6kg
Product Description
Specification
|
Model
|
DSP5 、DSP5 Pro、DSP5 Air
|
|
Applicable syringe size
|
2/3ml、5/6ml、10/12ml、20ml、30/35ml、50/60ml
|
|
Rate Range
|
2/3ml :0.01～160ml/h
5/6ml :0.01～400ml/h
10/12ml :0.01～800ml/h
20ml :0.01～1600ml/h
30/35ml :0.01～2400ml/h
50/60ml :0.01～3000ml/h
|
|
Rate step
|
0.01ml/h
|
|
Bolus rate & volume
|
2/3ml :0.01～160ml/h 0.1～2ml
5/6ml :0.01～400ml/h 0.1～5ml
10/12ml :0.01～800ml/h 0.1～10ml
20ml :0.01～1600ml/h 0.1～20ml
30/35ml:0.01～2400ml/h 0.1～30ml
50/60ml :0.01～3000ml/h 0.1～50ml
|
|
Bolus rate step
|
0.01ml/h
|
|
FF volume
|
0 ~maximum volume of syringe
|
|
KVO rate(manual mode)
|
0.01～30ml/h （ 0.01ml/h step）
|
|
VTBI (volume to be infused)
|
0～9999.99ml, 0.01ml step,(value"0" means no limit for VTBI )
|
|
Mechanical accuracy error
|
within ±0.5%
|
|
Pressure units
|
MPa、kPa、mmHg、inH2O、psi、mbar
|
|
Max injection pressure
|
within 250kPa
|
|
Dimensions
|
384mm（L）×223mm（W）×231mm（H）
|
|
Net weight
|
3.6kg
|
|
Gross weight
|
4.6kg
|
