Tyre Recycling Equipment ZPS-900 Waste Tyre Breaker

Tire Shredding

ZPS Tire Shredder is used to shred radial tire and fiber tire into tire chips of 50x50mm size in ambient process

the tire needs to be debeaded before shredding. It mainly consists of motor, speed reducer, machine frame,

shredding blades, rotary screener, transmission system, etc.

FEATURES:

1.The shredding chamber is closely mated with the left-hand drive. The cutter consists of blade and hooks. The function of hooks is to catch tires. Special anti-wear hard alloy is built-up welded on the working face of the cutter, which are durable and corrosion proof.

2.The shredding chamber is a combined structure and the cutter shaft is supported with rolling bearings, which is convenient for installation and maintenance.

3.The cylinder sieve or back-feed conveyer (optional) will repeatedly send those unqualified chips or shivers back to the shredding chamber, and at the same time send out those qualified ones.

4.The transmission system adopts a Hard Face Gear Reducer, which has a compacted structured with higher transmission efficiency, lower noise and longer service life.

5.The shredder is compactly structured and practically collocated. It is easy and reliable for operation and convenient for both installation and maintenance.

3-Technical parameter:
Model	ZPS-800	ZPS-1200
Production capacity	0.8-2 Ton/hour	1.5-3 T/h
Size of feeding	≤800 mm whole tyre	≤1200 mm whole tyre
Discharging particles	≤50*50mm	≤60*60mm
Motor powder	45 kw	155 kw
Discharging motor	2.2 kw	4 kw
Cutter rotate speed	16 r/min	31 r/min
Screener rotate speed	6 r/min	8 r/min
Dimension (L*W*H)	2.8*2.1*2.4 m	5.2*2.8*3.5 m
Weight	6.2 T	14.8 T

We use it as one of our waste tire recycling machine in our daily production to produce rubber powder, below is the whole production line:

We are professional rubber machine manufacturer with 10 years experiences in China.

All products have been certified by the State Bureau of Technical Supervision, and have
been exported to South Asia, mid East, East Europe, South and North America  Africa, Australia and so on.

Payment terms:

30% advanced payment, TT or L/C balance after shippment.

FAQ:

1.Q:Are you a factory or trading company?

A:We are factory.

2.Q:Where is your factory?How can i visit ?

A:Our factory located in qingdao city.You can fly to qingdao liuting airport,then we can pick you up to our  facotry to visit.Warm welcome visit us.

3.Q:How does your factory control the quality of machines and after sales service?

A:Our machines passed CE,BV,ISO,SGS certification,pls confirm the quality.All our machines have 1 year  guarantee, will provide lifetime maintenance.

Why choose us?

We are ready to give them a turnkey solution, by designing the line according to their space, designing all  electrical Installation, water installation, civil foundation, training their people and proving that they will get the targets for production according to the design.

The cost of the machinery they are paying is one off but the correct production design and machine configuration in order to get the production targets is the most important point. Even if somebody got the cheapest  machine quotation, at the end of the day, what is count are the production quantity, quality and the durability of the machines so to cover the investment in the correct time.

A satisfies customer can bring you ten more customers but one disappointed customer can send away one  hundred customers. Reputation in the market is the most important factor for keeping business healthy and in growing line.

Guarantee & After-sale service:

♥One year guarantee for whole machines

♥24 hours technical support by email

♥Calling or door - to -door service.

♥Provide videos for each machine.
