Quick Details
-
Voltage:
-
220V/380V
-
Weight:
-
3000 KG
-
Dimension(L*W*H):
-
3650*2160*2450 mm
-
Marketing Type:
-
New Product 2021
-
Product name:
-
Oxygen generator
-
Color:
-
White/ Customised
-
Purity:
-
90%-99.5%
-
Capacity:
-
5-3000Nm3/h
-
Material:
-
carbon steel
-
Type:
-
Pressure Swing Adsorption(PSA)
-
Technology:
-
PSA System
-
Application:
-
General Industrial Fields
-
Name:
-
PSA industrial oxygen generator
-
After-sales Service Provided:
-
Video technical support
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
LUOMING GAS
-
Production Rate:
-
100%
-
Voltage:
-
220V/380V
-
Weight:
-
3000 KG
-
Dimension(L*W*H):
-
3650*2160*2450 mm
-
Marketing Type:
-
New Product 2021
-
Product name:
-
Oxygen generator
-
Color:
-
White/ Customised
-
Purity:
-
90%-99.5%
-
Capacity:
-
5-3000Nm3/h
-
Material:
-
carbon steel
-
Type:
-
Pressure Swing Adsorption(PSA)
-
Technology:
-
PSA System
-
Application:
-
General Industrial Fields
-
Name:
-
PSA industrial oxygen generator
-
After-sales Service Provided:
-
Video technical support
Products Description
Principles of PSA Oxygen Generator
PSA ( Pressure Swing Adsorption) Technology a revolution in Non Cryogenic Air Separation and Oxygen Generation Technology uses special grade of ZMS ( Zeolite Molecular Sieve).
The compressed air is passed through a Twin Tower PSA module interconnected with automatic change over valves. After passing through a Refrigerated Dryer air gets dried. Dried compressed air will now come in contact with bed of Zeolite molecular sieves (ZMS). Zeolite Molecular Sieves are special grade of adsorbent which have the property of preferential adsorption of nitrogen molecules. At a time one tower remains under nitrogen production cycle, whereas the other tower undergoes regeneration which is achieved through depressurization of the tower to atmospheric pressure. The outgoing oxygen gas is sent to a surge vessel where the minimum pressure will be maintained with the help of Back pressure Regulator.
Technical Index
Compressed Air Pressure: 0.7-1.3MPa (7Bar-13Bar)
Oxygen Capacity: 3 - 200Nm3/h
Oxygen Purity: 93%±%
Outlet Pressure: 0.5MPa (Oxygen Generator) / 15MPa(Filling Manifold)
Dew Point: ≤-40℃
|
Product name
|
PSA industrial oxygen generator
|
|
Color
|
White/ Customised
|
|
Shape
|
Skid-mounted
|
|
Purity
|
90%-99.9999%
|
|
Material
|
Carbon Steel
|
|
Technology
|
PSA System
|
|
Application
|
General Industrial Fields
|
|
After-Sales Service Provided
|
Engineers available to service machinery overseas
|
