Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MUST
-
Model Number:
-
PH1800 Series-PH18-8048
-
Input Voltage:
-
300VAC
-
Output Voltage:
-
230VAC±5%
-
Output Current:
-
160A
-
Output Frequency:
-
60Hz or 50Hz
-
Size:
-
503*600*141.2mm
-
Certificate:
-
ce
-
Warranty:
-
1 years
-
Weight:
-
21kg
-
Storage Temperature:
-
-15°C ~60°C
-
Operating Temperature:
-
0°C~50°C
-
Charging Algorithm:
-
3-step (Flooded Battery / AGM / GEL/ LEAD Battery), 4-step(LI)
-
Maximum Charge Current:
-
280A
-
Cold Start Voltage:
-
46VDC
-
PV Array Open Circuit Voltage:
-
60-130VDC
-
AC Charging Current:
-
2-120A
-
Selectable Voltage Range:
-
170~280VAC (UPS) / 90~280VAC (APL) / 184~253VAC(VDE4105)
-
Transfer Time:
-
10ms (UPS) 20ms (APL)
-
Max AC Input Voltage:
-
300VAC
Quick Details
-
Output Type:
-
Single
-
Type:
-
DC/AC Inverters
-
Inverter Efficiency:
-
93%
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
MUST
-
Model Number:
-
PH1800 Series-PH18-8048
-
Input Voltage:
-
300VAC
-
Output Voltage:
-
230VAC±5%
-
Output Current:
-
160A
-
Output Frequency:
-
60Hz or 50Hz
-
Size:
-
503*600*141.2mm
-
Certificate:
-
ce
-
Warranty:
-
1 years
-
Weight:
-
21kg
-
Storage Temperature:
-
-15°C ~60°C
-
Operating Temperature:
-
0°C~50°C
-
Charging Algorithm:
-
3-step (Flooded Battery / AGM / GEL/ LEAD Battery), 4-step(LI)
-
Maximum Charge Current:
-
280A
-
Cold Start Voltage:
-
46VDC
-
PV Array Open Circuit Voltage:
-
60-130VDC
-
AC Charging Current:
-
2-120A
-
Selectable Voltage Range:
-
170~280VAC (UPS) / 90~280VAC (APL) / 184~253VAC(VDE4105)
-
Transfer Time:
-
10ms (UPS) 20ms (APL)
-
Max AC Input Voltage:
-
300VAC
Product Description
Specification
|
item
|
value
|
|
Place of Origin
|
China
|
|
|
Guangdong
|
|
Brand Name
|
MUST
|
|
Model Number
|
PH1800 Series-PH18-8048
|
|
Input Voltage
|
300VAC
|
|
Output Voltage
|
230VAC±5%
|
|
Output Current
|
160A
|
|
Output Frequency
|
60Hz or 50Hz
|
|
Output Type
|
Single, Triple
|
|
Size
|
503*600*141.2mm
|
|
Type
|
DC/AC Inverters
|
|
Inverter Efficiency
|
93%
|
|
Certificate
|
ce
|
|
Warranty
|
1 years
|
|
Weight
|
21kg
|
|
Storage Temperature
|
-15°C ~60°C
|
|
Operating Temperature
|
0°C~50°C
|
|
Charging Algorithm
|
3-step (Flooded Battery / AGM / GEL/ LEAD Battery), 4-step(LI)
|
|
Maximum Charge Current
|
280A
|
|
Cold Start Voltage
|
46VDC
|
|
PV Array Open Circuit Voltage
|
60-130VDC
|
|
AC Charging Current
|
2-120A
|
|
Selectable Voltage Range
|
170~280VAC (UPS) / 90~280VAC (APL) / 184~253VAC(VDE4105)
|
|
Transfer Time
|
10ms (UPS) 20ms (APL)
|
|
Max AC Input Voltage
|
300VAC
|
