Quick Details
-
Invoicing:
-
by theoretical weight
-
Place of Origin:
-
Shandong, China
-
Thickness:
-
5-34mm
-
Application:
-
Industrial structure
-
Length:
-
6-12m/pc or as your request
-
Flange Width:
-
100mm-300mm, 75-400mm
-
Flange Thickness:
-
8mm-28mm
-
Web Width:
-
100mm-900mm
-
Web Thickness:
-
6mm-16mm
-
Brand Name:
-
ZhiKai
-
Model Number:
-
Q235,Q345,SS400,S235JR, S345JR,St37-2,St52
-
Product name:
-
H-Beam
-
Shape:
-
H-channel
-
Technical:
-
Hot Rolled Beam
-
Key words:
-
H-shaped Structural Steel
-
Material:
-
Q235/Q345/ST37-2/ST52/Q420/Q460/S235JR/S275JR/S355JR
-
Usage:
-
Commercial Buildings
-
MOQ:
-
1 Ton
-
Surface:
-
Natural Surface
-
Type:
-
H-bar
Quick Details
-
Grade:
-
Q235B
-
Standard:
-
ASTM
-
Tolerance:
-
±1%
-
Invoicing:
-
by theoretical weight
-
Place of Origin:
-
Shandong, China
-
Thickness:
-
5-34mm
-
Application:
-
Industrial structure
-
Length:
-
6-12m/pc or as your request
-
Flange Width:
-
100mm-300mm, 75-400mm
-
Flange Thickness:
-
8mm-28mm
-
Web Width:
-
100mm-900mm
-
Web Thickness:
-
6mm-16mm
-
Brand Name:
-
ZhiKai
-
Model Number:
-
Q235,Q345,SS400,S235JR, S345JR,St37-2,St52
-
Product name:
-
H-Beam
-
Shape:
-
H-channel
-
Technical:
-
Hot Rolled Beam
-
Key words:
-
H-shaped Structural Steel
-
Material:
-
Q235/Q345/ST37-2/ST52/Q420/Q460/S235JR/S275JR/S355JR
-
Usage:
-
Commercial Buildings
-
MOQ:
-
1 Ton
-
Surface:
-
Natural Surface
-
Type:
-
H-bar
|
Shape
|
H beam
|
|
Material
|
Q235 Q345 SS400 ST37-2/ST52.etc
|
|
Technology
|
Hot Rolled
|
|
Thickness
|
5-34mm,As Customer's Required
|
|
Lenath
|
As Customer's Required
|
|
Usage
|
Commercial Buildings
|
|
Packing
|
Strong Woden Box or according to customer request
|
|
Surface
|
Colored&polish&customization
|
|
Specification of Steel H Section Beam
|
|
|
|
|||
|
Size
|
Weight(Kg/M)
|
Size
|
Weight(Kg/M)
|
|||
|
100*50*5*7
|
9.54
|
390*300*10*16
|
107
|
|||
|
100*100*6*8
|
17.2
|
394*398*11*18
|
147
|
|||
|
125*60*6*8
|
13.3
|
396*199*7*11
|
56.7
|
|||
|
125*125*6.5*9
|
23.8
|
400*200*8*13
|
66
|
|||
|
148*100*6*9
|
21.4
|
400*400*13*21
|
172
|
|||
|
150*75*5*7
|
14.3
|
400*408*21*21
|
197
|
|||
|
150*150*7*10
|
31.9
|
414*405*18*28
|
233
|
|||
|
175*90*5*8
|
18.2
|
428*407*20*35
|
284
|
|||
|
175*175*7.5*11
|
40.4
|
440*300*11*18
|
124
|
|||
|
194*150*6*9
|
31.2
|
446*199*8*12
|
66.7
|
|||
|
198*99*4.5*7
|
18.5
|
450*200*9*14
|
76.5
|
|||
|
200*100*5.5*8
|
21.7
|
458*417*30*50
|
415
|
|||
|
200*200*8*12
|
50.5
|
482*300*11*15
|
115
|
|||
|
200*204*12*12
|
56.7
|
488*300*11*18
|
129
|
|||
|
244*175*7*11
|
44.1
|
496*199*9*14
|
79.5
|
|||
|
248*124*5*8
|
25.8
|
498*432*45*70
|
605
|
|||
|
250*125*6*9
|
29.7
|
500*200*10*16
|
89.6
|
|||
|
250*250*9*14
|
72.4
|
506*201*11*19
|
103
|
|||
|
250*255*14*14
|
82.2
|
582*300*12*17
|
137
|
|||
|
294*200*8*12
|
57.3
|
588*300*12*20
|
151
|
|||
|
294*302*12*12
|
85
|
594*302*14*23
|
175
|
|||
|
298*149*5.5*8
|
32.6
|
596*199*10*15
|
95.1
|
|||
|
300*150*6.5*9
|
37.3
|
600*200*11*17
|
106
|
|||
|
300*300*10*15
|
94.5
|
606*201*12*20
|
120
|
|||
|
300*305*15*15
|
106
|
692*300*13*20
|
166
|
|||
|
340*250*9*14
|
79.7
|
700*300*13*24
|
185
|
|||
|
344*348*10*16
|
115
|
792*300*14*22
|
191
|
|||
|
346*174*6*9
|
41.8
|
800*300*14*26
|
210
|
|||
|
350*175*7*11
|
50
|
890*299*15*23
|
213
|
|||
|
350*350*12*19
|
137
|
900*300*16*28
|
243
|
|||
|
388*402*15*15
|
141
|
912*302*18*34
|
286
|
|||
Q1 : What product information must I provide before making a purchase ?
Please provide the grade , width , thickness , and surfacetreatment requirements , as well asthe quantities you require .
Q2 : What shipping ports are there ?
We normally ship from Shanghai , Tianjin , Qingdao , and Ningbo ports
Q3 : What are your payment terms ?
30%T /T in advance and 70% balance before shipment or based onbl copy or LC at sight
Q4 : What about product pricing information ?
Prices vary due to changes in raw material prices on a regular basis
Q5 : ls it possible to send samples ?
Of course , we offer free samples and express shipping to customers all over the world .
Q6 : Do you offer a service for customized products ?
Yes , we can produce according to your specifications and drawings
Q7 : Can I pay you a visit at your factory ?
Customers from all around the world are welcome to visit our factory .
Q8 : Can you assist me in importing steel products for the first time ?
Yes , we have shipping agent
