Name: wood seat
Brand: HUAHENG
Original: CHINA
Customer can choose split long or short wood
- Product Details
- {{item.text}}
Quick Details
-
Dimension(L*W*H):
-
850L*750W*2020H mm
-
Weight:
-
450 KG
-
Key Selling Points:
-
tractor log splitter
-
Color:
-
Customized
-
Power:
-
PTO
-
User manual:
-
Log Splitter User Manual
-
Product name:
-
pto log splitter
-
Application:
-
wood splitting
-
Cylinder:
-
5 inch
-
Pump:
-
16GPM
-
Valve:
-
4 stage valve
-
Package:
-
Steel pallet
-
Max. log diameter:
-
500mm
-
Local Service Location:
-
United Kingdom
-
After-sales Service Provided:
-
Free spare parts, Video technical support, Online support
-
Certification:
-
CE EPA
Quick Details
-
Use:
-
Split Wood
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HUAHENG
-
Dimension(L*W*H):
-
850L*750W*2020H mm
-
Weight:
-
450 KG
-
Key Selling Points:
-
tractor log splitter
-
Color:
-
Customized
-
Power:
-
PTO
-
User manual:
-
Log Splitter User Manual
-
Product name:
-
pto log splitter
-
Application:
-
wood splitting
-
Cylinder:
-
5 inch
-
Pump:
-
16GPM
-
Valve:
-
4 stage valve
-
Package:
-
Steel pallet
-
Max. log diameter:
-
500mm
-
Local Service Location:
-
United Kingdom
-
After-sales Service Provided:
-
Free spare parts, Video technical support, Online support
-
Certification:
-
CE EPA
Product Description
Product Application
for wood splitting.
Tractor PTO driven
|
SPECIFICATIONS FOR PTO LOG SPLITTER
|
|
|
|
|||
|
Model No.
|
LS1050-PTO
|
Qty for 20gp
|
27 units
|
|||
|
Description
|
Tractor driven,vertical working position,four position valve control fast and slow two different splitting speed.
|
Packing size
|
850X750X2020mm
|
|||
|
Splitting capacity
|
500*1050mm
|
Weight
|
435kgs
|
|||
|
Cylinder diameter
|
5 inch
|
Warranty time
|
12 months
|
|||
|
Cylinder stroke
|
1050mm
|
Max splitting force
|
35Ton
|
|||
|
Pump
|
2 stage 16GPM
|
Oil Tank capacity
|
26L
|
|||
Certifications
Detailed Images
Machine Parts
Main Features
Name: 4 way wedge suit
Brand: Huaheng
Original: CHINA
TO split wood in 2 way or 4 way pieces
Machine Parts
Name:
valve
Brand: Huaheng
Original:
CHINA
4 stage valve can control to split wood fast or slow 2 speed
Main Features
Name:
pump
Brand: HUAHENG
Original: China
Top quality 2 stage 16gpm pump
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Offer warranty parts during 1 year time.
Packing & Delivery
|
Packaging
|
|
|
|
Size
|
700 (L) * 600 (W) * 1890 (D)mm
|
|
|
Weight
|
380KGS
|
|
|
Packaging Details
|
The normal package is steel pallet. If export to european countries,the wooden box will be ok.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
|
|
