Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KAI HUI
-
Model Number:
-
KPS24
-
Output Frequency:
-
50~60Hz
-
Output Current:
-
2A
-
Name:
-
220v ac to 24v dc pcb new 24w switching power supply
-
Ripple & Noise:
-
100mVp-p
-
Weight:
-
0.06Kg
-
Overload protection:
-
105~130%,Hiccup, automatic recovery protection
-
Efficiency:
-
84%
-
Leakage Current:
-
<0.25mA@240V AC
-
Demension:
-
50*40*25mm(Lengh*Width*Height)
-
Setup,Rise,Hold up time:
-
500ms,30ms,16ms/115VAC ; 300ms 30ms 50ms/230VAC
-
EMC Standards:
-
GB9254,Class A
-
Application:
-
LED Lighting, inkjet Printer, LED Screen etc.
Quick Details
-
Output Power:
-
24W
-
Input Voltage:
-
100-240V AC
-
Output Voltage:
-
DC12V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
KAI HUI
-
Model Number:
-
KPS24
-
Output Frequency:
-
50~60Hz
-
Output Current:
-
2A
-
Name:
-
220v ac to 24v dc pcb new 24w switching power supply
-
Ripple & Noise:
-
100mVp-p
-
Weight:
-
0.06Kg
-
Overload protection:
-
105~130%,Hiccup, automatic recovery protection
-
Efficiency:
-
84%
-
Leakage Current:
-
<0.25mA@240V AC
-
Demension:
-
50*40*25mm(Lengh*Width*Height)
-
Setup,Rise,Hold up time:
-
500ms,30ms,16ms/115VAC ; 300ms 30ms 50ms/230VAC
-
EMC Standards:
-
GB9254,Class A
-
Application:
-
LED Lighting, inkjet Printer, LED Screen etc.
PCB open frame 24v 1a smps+24v 1a psu
Features:
With wide application, they had been used in LED lighting,ACS,medical and beauty device,electrical power system,communication system,military industry and others .
2, Some models a chieved GS,CE,CCC,ETL,ISO,ROHS certification now.
3, There are more than 1,000 kinds of models .
|
1, High efficiency, low temperature rise; |
|||||||
|
2, Includes filters, low output noise; |
|||||||
|
3, Wide range AC input voltage; |
|||||||
|
4. Short circuit, overload, overvoltage protection. |
|||||||
|
parameter Item No. |
KPS24-5 |
KPS24-12 |
KPS24-24 |
KPS24-36 |
|||
|
OUTPUT
|
DC Output Voltage |
+5V | +12V |
+24V |
+36V |
||
|
Output Rated Current |
4A | 2A | 1A | 0.7A | |||
|
Output C urrent Range |
0-4 A | 0-2 A | 0- 1A | 0-0.7A | |||
|
Rated power |
20W | 24W | 24W | 25.2W | |||
|
Ripple |
50mVp-p | 120 mVp-p | 24 0 mVp-p | 360mVp-p | |||
|
ADJ.output range |
------- | ||||||
|
Output Accuracy |
±4% | ||||||
|
Line Regulation |
±2% |
||||||
|
Load Regulation |
±2% |
||||||
|
Setup,Rise, Hold up time |
500ms,30ms,16ms/115VAC; 300ms,30ms,50ms/230VAC |
||||||
|
INPUT
|
Input Voltage range |
100-240V AC | |||||
|
Input current |
0.22A/115V 0.11A/230V |
||||||
|
Input frequency |
50~60Hz |
||||||
|
Efficiency |
78% |
84% |
85% |
85% |
|||
| Leakage Current | <0.25mA@240V | ||||||
|
Over Temp.protection |
Over load protection | 105~130%,Hiccup, automatic recovery | |||||
| Over voltage | ------ | ||||||
| Over Temp. | ------ | ||||||
|
ENVIRONMENT
|
Working Temp., Humidity |
-10~50℃,10~90% RH, No condensation |
|||||
|
Storage Temp.,Humidity |
-20~85℃,10~95% RH. |
||||||
|
Temp.Coefficeent |
±0.03%/℃(0~50℃) |
||||||
|
Vibration |
10~500Hz, 2G 10min./1cycle, PERIOD FOR 60min. EACH AXES |
||||||
|
SAFETY&EMC
|
Safety standards |
GB4943 |
|||||
| Withstand voltage |
I/P-O/P, 3KV: DC 1min. |
||||||
|
Insulation resistance |
I/P-O/P, 500VDC / 100M Ohms |
||||||
|
EMC standards |
GB9254 CLASS A |
||||||
|
OTHER
|
Demension |
50*40*25mm |
|||||
|
Weight |
0.06Kg |
||||||
| Note: |
1. All parameters 220VAC input, rated load, ambient temperature 25 ℃, measured under conditions of 70%
humidity; 2.Accuracy: includes set up tolerance, line regulation, load regulation and so on; 3. Ripple Test: 30cm long strands connect the power supply and the load, the load side and 0.1u and 47u capacitor to 20MHz oscilloscope measured at the load end; 4. Line regulation: at rated load conditions, the input voltage changes from low to high measured; 5. Load regulation: the measured output from 0% to 100% load change load measured. |
|
Payment&Shipping
Payment
Shipping
|
Q1. Can I have a sample order for power supply?
A
1
: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2: Do you accept OEM /ODM for the switching power supply ?
A2: Yes. we do .
Q3: How about the quality?
A3: We have the better professional and experienced engineers team and strict QA and QC system.Repair rate under 0.1%~0.2%
Q4:
What is PFC?
A4:
PFC stands for Power Factor Correction. The purpose of PFC is to improve the ratio of apparent power and real power. The power factor is only 0.
5
~0.
7
in non-PFC models. In PFC models, the power factor can reach above 0.9. The calculation formulas are as below:
Apparent Power=Input Voltage x Input Current (VA)
Real Power= Input Voltage x Input Current x Power Factor (W)
