- Product Details
- {{item.text}}
Quick Details
-
Throat Depth (mm):
-
400 mm
-
Width of Working Table (mm):
-
60 mm
-
Dimension:
-
3800*1800*2750mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
BLMA
-
Year:
-
2022
-
Weight (KG):
-
8500
-
Motor Power (kw):
-
7.5 kw
-
Back-GaugeRange:
-
10-600mm
-
Valve:
-
Rexroth, Germany
-
Color:
-
Blue&white/cutomized
-
Norminal force:
-
1000KN
-
Bending length:
-
3200mm
-
Throat depth:
-
2700
Quick Details
-
Machine Type:
-
Synchronized
-
Length of Working Table (mm):
-
3200
-
Slider Stroke (mm):
-
200 mm
-
Throat Depth (mm):
-
400 mm
-
Width of Working Table (mm):
-
60 mm
-
Dimension:
-
3800*1800*2750mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
BLMA
-
Year:
-
2022
-
Weight (KG):
-
8500
-
Motor Power (kw):
-
7.5 kw
-
Back-GaugeRange:
-
10-600mm
-
Valve:
-
Rexroth, Germany
-
Color:
-
Blue&white/cutomized
-
Norminal force:
-
1000KN
-
Bending length:
-
3200mm
-
Throat depth:
-
2700
Main Features
The fuselage adopts
integral welding and integral processing structure
. The main components of the fuselage are analyzed by ANSYS finite element analysis software to ensure the reliability and accuracy of the fuselage.
Adopting the closed-loop control method composed of
German electro-hydraulic servo valve and grating ruler
, the slider position feedback accuracy is high, the operation is accurate and stable, the synchronization performance is good, and the bending accuracy is high.
The numerical control system can realize the functions of
bending angle graphic programming
,
angle correction compensation
,automatic calculation and automatic adjustment of bending pressure, automatic calculation of the deformation compensation amount of the worktable, the unfolded length of the work piece, and the automatic back gauge of the back gauge.
Machine details
Systems
Detailed Description
Product Paramenters
Bending sample
