Quick Details
-
Application:
-
Villa
-
Design Style:
-
Contemporary
-
Type:
-
mgso4 panel
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
VOGUE
-
Model Number:
-
1220*2440
-
thickness:
-
3mm to 25mm
-
Color:
-
white, grey
-
Material:
-
Mgo + floating bead
-
Usage:
-
Thermal Insulation Wall Panel
-
Certification:
-
ISO 9001-2015
-
Advantage:
-
100% Non-Chloride
-
Density:
-
0.95-1.1kg/m3
-
Bend strength:
-
10Mpa-20Mpa
-
Screw holding strength:
-
1000N
-
Fireproof Grade:
-
A1 Non-combustible
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
graphic design
-
Application:
-
Villa
-
Design Style:
-
Contemporary
-
Type:
-
mgso4 panel
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
VOGUE
-
Model Number:
-
1220*2440
-
thickness:
-
3mm to 25mm
-
Color:
-
white, grey
-
Material:
-
Mgo + floating bead
-
Usage:
-
Thermal Insulation Wall Panel
-
Certification:
-
ISO 9001-2015
-
Advantage:
-
100% Non-Chloride
-
Density:
-
0.95-1.1kg/m3
-
Bend strength:
-
10Mpa-20Mpa
-
Screw holding strength:
-
1000N
-
Fireproof Grade:
-
A1 Non-combustible
Products data
| Chemical composition | Magnesium oxide,magnesium chlo-ride,saw dust,perlite,glass fiber cloth,non-woven cloth | |||||||
| Material | Modified magnesia cement | |||||||
| Fireproofing characteristic | A grade non combustible(GB8624) | |||||||
| Density | 0.8-1.1g/cm 3 | |||||||
| Intensity of bending resistance when dry | 18Mpa(GB/T7019-1997) | |||||||
| Intensity of bending resistance when moisture-saturated condition | 22Mpa(GB/T7019-1997) | |||||||
| The rate of deformation when pick up the moisture | 0.26%(GA160-1997) | |||||||
| The shrinking rate when heated | 1.0%(GA160-1997) | |||||||
| Water permeability | there is no drop of water to emerge in the back(CNS13778) | |||||||
| Impact resistance | No crack,strip and run through(CNS13778) | |||||||
| Thermal resistance | 1.14m 2 k/w(GB/T 13475-92) | |||||||
| Sound insulation | ≥44db(GBJ121-88) | |||||||
| Color | white or grey | |||||||
| Security | 100% does not include the asbestos,formaldehyde,and benzene | |||||||
| Radioactivity | Not limited by the scope of application(GB6566-2001) | |||||||
