- Product Details
- {{item.text}}
Quick Details
-
Ejector Stroke(mm):
-
120 mm
-
Ejector Force(kN):
-
31 kN
-
Theoretical Shot Volume(cm³):
-
68 cm³
-
Injection Rate (g/s):
-
62 g/s
-
Injection Weight (g):
-
62 g
-
Screw Speed (rpm):
-
1 - 266 rpm
-
Screw diameter (mm):
-
25 mm
-
Screw L/D Ratio:
-
24
-
Distance between Tie Bars:
-
290x290
-
Weight (KG):
-
2000
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
240 mm
-
Model Number:
-
SB650V
-
Brand Name:
-
SUNBUN
-
Power (kW):
-
5.5 kW
-
After-sales Service Provided:
-
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Egypt, Turkey, Brazil, Indonesia, Russia, Morocco, Algeria, Bangladesh, Ukraine
-
Certification:
-
CE, ROHS
-
Marketing Type:
-
New Product 2021
Quick Details
-
Distance between Tie Bars(Width)(mm):
-
290mm
-
Distance between Tie Bars(Height)(mm):
-
290mm
-
Mold Height(mm):
-
80 - 340 mm
-
Ejector Stroke(mm):
-
120 mm
-
Ejector Force(kN):
-
31 kN
-
Theoretical Shot Volume(cm³):
-
68 cm³
-
Injection Rate (g/s):
-
62 g/s
-
Injection Weight (g):
-
62 g
-
Screw Speed (rpm):
-
1 - 266 rpm
-
Screw diameter (mm):
-
25 mm
-
Screw L/D Ratio:
-
24
-
Distance between Tie Bars:
-
290x290
-
Weight (KG):
-
2000
-
Place of Origin:
-
Zhejiang, China
-
Open Stroke(mm):
-
240 mm
-
Model Number:
-
SB650V
-
Brand Name:
-
SUNBUN
-
Power (kW):
-
5.5 kW
-
After-sales Service Provided:
-
Video technical support, Free spare parts, Field installation, commissioning and training, Field maintenance and repair service, Online support
-
After Warranty Service:
-
Video technical support, Online support, Spare parts, Field maintenance and repair service
-
Local Service Location:
-
Egypt, Turkey, Brazil, Indonesia, Russia, Morocco, Algeria, Bangladesh, Ukraine
-
Certification:
-
CE, ROHS
-
Marketing Type:
-
New Product 2021
Product Description
Specification
|
Injection Part
|
Item/type
|
Unit
|
SB650
|
|
|
||
|
|
Screw type
|
|
A
|
B
|
C
|
||
|
|
Screw diameter
|
mm
|
25
|
28
|
32
|
||
|
|
Screw diame-ter ratio
|
L/D
|
24
|
21.4
|
18.8
|
||
|
|
Theoretical injection volume
|
cm³
|
68
|
86
|
112
|
||
|
|
Injection volume (PS)
|
g
|
62
|
78
|
102
|
||
|
|
Injection pressure
|
MPa
|
265
|
211
|
162
|
||
|
|
Injection stroke
|
mm
|
218
|
|
|
||
|
|
Maximal Rotational Speed of Screw
|
r/min
|
266
|
|
|
||
|
Clamping Part
|
Clamp Tonnage
|
KN
|
650
|
|
|
||
|
|
Toggle stroke
|
mm
|
240
|
|
|
||
|
|
Distance between tie bars
|
mm
|
290x290
|
|
|
||
|
|
Mold Size
|
mm
|
430x430
|
|
|
||
|
|
Ejection stroke
|
mm
|
120
|
|
|
||
|
|
Ejector force forward
|
KN
|
31
|
|
|
||
|
|
Amount of die thimble
|
Pcs
|
1
|
|
|
||
|
|
System pressure
|
Mpa
|
17.5
|
|
|
||
|
|
Motor power
|
KW
|
5.5
|
7.5
|
7.5
|
||
|
|
Heater power
|
KW
|
4.45
|
|
|
||
|
|
Positioning Hole Dia
|
mm
|
80
|
|
|
||
|
|
Nozzle Ball Radius
|
mm
|
SR10
|
|
|
||
|
|
Oil tank capacity
|
L
|
150
|
|
|
||
|
|
Boundary dimension(L×W×H)
|
m
|
3.3x1.0x1.7
|
|
|
||
|
|
Machine weight
|
Ton
|
2.0
|
|
|
||
INJECTION SYSTEM
CLAMPING SYSTEM
HYDRAULIC SYSTEM
ELECTRONIC CONTROL SYSTEM
Application
Auto parts
Sanitation products
Medical field
Black and white household appliance
Toy industry
Home appliances
Powder box
Lipstick
Shoes material products
