Quick Details
-
The discharge rate:
-
780A(5S)
-
Warranty:
-
3 years, 3 years
-
Battery Size:
-
12V 100/200Ah
-
Brand Name:
-
Greensun
-
Model Number:
-
FM60-12
-
Place of Origin:
-
Jiangsu, China
-
Weight:
-
20kg
-
Product name:
-
Tubular lead acid battery 12v
-
OEM Order:
-
Acceptable
-
Separator:
-
absorbent glass mat (GEL)
-
Material:
-
High Pure Lead
-
Container Material:
-
ABS
-
Certification:
-
CE ISO RoHS MSDS
-
Type:
-
AGM Lead Acid Battery
-
Delivery time:
-
15 working days
Quick Details
-
Chargeable:
-
Yes
-
Battery Type:
-
Deep Cycle: Sealed AGM
-
Cycle Life:
-
4000 cycles
-
The discharge rate:
-
780A(5S)
-
Warranty:
-
3 years, 3 years
-
Battery Size:
-
12V 100/200Ah
-
Brand Name:
-
Greensun
-
Model Number:
-
FM60-12
-
Place of Origin:
-
Jiangsu, China
-
Weight:
-
20kg
-
Product name:
-
Tubular lead acid battery 12v
-
OEM Order:
-
Acceptable
-
Separator:
-
absorbent glass mat (GEL)
-
Material:
-
High Pure Lead
-
Container Material:
-
ABS
-
Certification:
-
CE ISO RoHS MSDS
-
Type:
-
AGM Lead Acid Battery
-
Delivery time:
-
15 working days
Product Description
Key Features:
♦Safety seal, Deflating system ,Simple maintenance, long lasting,Stable quality and high reliability
♦Gelled electrolyte made by mixing sulfuric acid with silica fume.
♦The electrolyte is gel like, immobile and does not leak, enabling
uniform reaction of each part of the plate.
♦High rate discharge performance due to tight assembly technology
♦Strong heat dissipation and wide operating temperature range
♦Avoid acid mist being separated out, environment friendliness
♦Efficient venting system release excessive gas automatically
♦Gelled electrolyte made by mixing sulfuric acid with silica fume.
♦The electrolyte is gel like, immobile and does not leak, enabling
uniform reaction of each part of the plate.
♦High rate discharge performance due to tight assembly technology
♦Strong heat dissipation and wide operating temperature range
♦Avoid acid mist being separated out, environment friendliness
♦Efficient venting system release excessive gas automatically
Specification
|
Battery Model
|
FM4-12
|
FM7-12
|
FM12-12
|
FM17-12
|
FM24-12
|
FM60-12
|
|||||
|
Nominal Voltage
|
12 Volt
|
|
|
|
|
|
|||||
|
Nominal Capacity
(10HR)
|
4AH
|
7AH
|
12AH
|
17AH
|
24AH
|
60AH
|
|||||
|
Dimensions
L*W*H
|
90*70*101
|
151*53*93
|
151*98*95
|
181*77*167
|
166*175*125
|
348*167*178
|
|||||
|
Max. Discharge Current
|
60A (5s)
|
75A (5s)
|
180A (5s)
|
225A (5s)
|
360A (5s)
|
780A (5s)
|
|||||
|
Terminal (Optional)
|
T1/
|
T1/T2
|
T1/T2
|
T3
|
T3
|
T6
|
|||||
|
Operating Temp.Range
|
Discharge : -15 ~ 50℃ (5~122°F)
Charge : 0 ~ 40℃ (32-104°F)
Storage : -15 ~ 40℃ (5~104°F)
|
|
|
|
|
|
|||||
|
Nominal Operating Temp.Range
|
25 ± 3℃ (77±5°F)
|
|
|
|
|
|
|||||
|
Internal Resistance
|
Approx 4.9mΩ
|
Approx 4.0mΩ
|
Approx 3.5mΩ
|
Approx 2.7mΩ
|
Approx 2.5mΩ
|
Approx 2.5mΩ
|
|||||
|
Cycle Use
|
14.4V~15.0V at 25 ℃(77 ºF)Temp. Coefficient -30mV/ C
|
|
|
|
|
|
|||||
|
Standby Use
|
13.5V~13.8V at 25 ℃(77 ºF)Temp. Coefficient -20mV/ C
|
|
|
|
|
|
|||||
|
Container Material
|
ABS
|
|
|
|
|
|
|||||
