Quick Details
-
Brand Name:
-
Calculus
-
Model Number:
-
60V 11A
-
Output Frequency:
-
45-60hz
-
Output Current:
-
11A
-
Product Name:
-
CPS-6011
-
Full load input current (220Vac):
-
≤3.35A
-
Net weight:
-
2.5KG
-
No load input current (220V)::
-
≤ 180mA
-
Ammeter accuracy:
-
≤ 0.3%+2 digit
-
Efficiency (220Vac / full load)::
-
≥89%
-
Voltmeter accuracy:
-
≤ 0.3%+1 digits
-
Warranty:
-
1 Year
-
MOQ:
-
1 Piece
-
Payment:
-
TT\Credit card\Trade Assurance
Quick Details
-
Input Voltage:
-
220V
-
Output Voltage:
-
0 - 60V
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Calculus
-
Model Number:
-
60V 11A
-
Output Frequency:
-
45-60hz
-
Output Current:
-
11A
-
Product Name:
-
CPS-6011
-
Full load input current (220Vac):
-
≤3.35A
-
Net weight:
-
2.5KG
-
No load input current (220V)::
-
≤ 180mA
-
Ammeter accuracy:
-
≤ 0.3%+2 digit
-
Efficiency (220Vac / full load)::
-
≥89%
-
Voltmeter accuracy:
-
≤ 0.3%+1 digits
-
Warranty:
-
1 Year
-
MOQ:
-
1 Piece
-
Payment:
-
TT\Credit card\Trade Assurance
Product Description
Microprocessor (MCU) control, high cost performance
High power density, compact and beautiful appearance
Full metal case, very low electromagnetic interference
Using encoder to adjust voltage and current, setting fast, accurate, convenient, fast and reliable
Four digit voltmeter and ammeter, set and display accurate to two decimal places
Active power factor correction (Active PFC), power factor >97% at rated output;
High efficiency, efficiency up to 90%
Low ripple noise, ripple peak less than 30mV
Output ON/OFF switch
Intelligent protection: output short-circuit protection, Tracking overvoltage protection (Tracking OVP), tracking overcurrent
protection (Tracking OCP), overtemperature protection (OTP)
Output ON/OFF
Operating voltage range 170 -- 264Vac
Operating frequency range 45-65 Hz
Output voltage range 0-60V
Output current ranges from 0 to 11A
Efficiency (220Vac, full load) ≥ 89%
Full load input current (220Vac) ≤3.35A
No-load input current (220Vac) ≤ 180mA
Voltmeter accuracy ≤ 0.3% + 1 digits
Ammeter accuracy ≤ 0.3% + 2 digit
Constant Voltage
Load Regulation (0-100%) ≤ 30mV
Line Regulation(198-264Vac) ≤ 10mV
Ripple & Noise (Peak-Peak) ≤ 30mV
Ripple & Noise (r.m.s) ≤ 3mV
Set Accuracy ≤ 0.3% + 10mV
Transient Response Time (50%-100% rated Load) ≤ 1.0ms
Constant Current
Load regulation rate (90%-10% Rated Voltage) ≤ 50mA
Input voltage regulation rate (198-264Vac) ≤ 20mA
Ripple current noise (peak-peak) ≤ 30 map-p
Setting accuracy ≤ 0.3% + 20mA
Dimensions (width × height × depth) 180×80×268mm
Weight 2.5KG
SPECIFICATION
|
Net weight
|
2.5KG
|
|
Place of Origin
|
China
|
|
Province
|
Guangdong
|
|
Model Number
|
CPS-6011
|
|
Operating voltage range
|
170 - 264Vac
|
|
Output Power
|
other
|
|
Output voltage range
|
0 - 60V
|
|
Operating frequency range
|
170 - 264Vac
|
|
Operating frequency range
|
45 - 65HZ
|
|
Setting accuracy
|
≤0.2%+ 3mA
|
|
Output Current
|
11A
|
|
Product name
|
CPS-6011
|
|
Input voltage regulation rate
|
≤ 20mA
|
|
Ammeter accuracy
|
≤0.1%+ 3 digits
|
|
Warranty
|
1 Year
|
|
OEM&ODM
|
Accept
|
|
Ammeter accuracy
|
≤ 0.3%+2 digit
|
|
imensions (width × high × Depth)
|
188×80×238mm
|
|
Feature1
|
power supply for phone PC
|
|
Feature2
|
switching power supply
|
