Quick Details
-
Voltage:
-
NO
-
Dimension(L*W*H):
-
5220x1750x1220mm
-
Application:
-
Home
-
Weight (KG):
-
550 KG
-
Marketing Type:
-
New Product 2023
-
Max cutting width:
-
635mm
-
Min cutting width:
-
76mm
-
Max wood thickness:
-
50mm
-
carbide blade quantity:
-
2
-
blade diameter:
-
305mm
-
Blade adjustment:
-
Manual
-
Blade position:
-
1 fixed , 1 adjustable
-
Min distance between blades:
-
76mm
-
Hydraulic feeding:
-
Forward & Reverse
-
Working pressure:
-
11Mpa
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
RIMA
-
Usage:
-
EDGE WOOD
-
Voltage:
-
NO
-
Dimension(L*W*H):
-
5220x1750x1220mm
-
Application:
-
Home
-
Weight (KG):
-
550 KG
-
Marketing Type:
-
New Product 2023
-
Max cutting width:
-
635mm
-
Min cutting width:
-
76mm
-
Max wood thickness:
-
50mm
-
carbide blade quantity:
-
2
-
blade diameter:
-
305mm
-
Blade adjustment:
-
Manual
-
Blade position:
-
1 fixed , 1 adjustable
-
Min distance between blades:
-
76mm
-
Hydraulic feeding:
-
Forward & Reverse
-
Working pressure:
-
11Mpa
Product Description
Specification
|
Model
|
WE635
|
|
|
Power
|
14HP Kohler gas engine, E-start
|
|
|
Cutting Capacities
|
|
|
|
Max cutting width
|
635mm(25”)
|
|
|
Min. cutting width
|
76mm(3”)
|
|
|
Max. wood thickness
|
50mm(2”)
|
|
|
Carbide Blades
|
|
|
|
Blade number
|
2pcs
|
|
|
Blade diameter
|
305mm(12”)
|
|
|
Blade adjustment
|
Manual
|
|
|
Blade position
|
1x fixed and 1x adjustable
|
|
|
Min distance between blades
|
76mm(3”)
|
|
|
Feed system & Operation
|
|
|
|
Max. feed speed
|
18m/min
|
|
|
Feed system
|
Powered rollers
|
|
|
Hydraulic feeding
|
Forward & Reverse
|
|
|
Wood hold-down
|
Hold-down rollers
|
|
|
Hold-down rollers Qty.
|
2pcs
|
|
|
Operation control
|
Manual control panel
|
|
|
Hydraulic System
|
|
|
|
Working pressure
|
11Mpa
|
|
|
Hydraulic tank capacity
|
16L
|
|
|
Hydraulic flow
|
7.3L/min
|
|
|
Tables
|
|
|
|
Infeed table length
|
2000mm
|
|
|
Outfeed table length
|
2000mm(Fold)
|
|
|
Others
|
|
|
|
Draw bar
|
50mm(2”)
|
|
|
Trailer tyre
|
2x12inch high speed wheel
|
|
|
Jack
|
4pcs
|
|
|
Sawdust collector hoppers
|
1pcs
|
|
|
Working caution light
|
YES
|
|
|
Laser position
|
YES
|
|
|
Ruler
|
YES
|
|
|
Dimension
|
5220x1750x1220mm
|
|
|
Weight
|
550kg
|
|
|
40” Container
|
24pcs
|
|
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
