Quick Details
-
Mounting Type:
-
Screw to fix by the aluminum rail
-
Description:
-
Integrated rubber safety edge, Safety edge sensor
-
Model Number:
-
FA-108
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FT
-
Theory:
-
Anti-clip Anti-collision Anti-pinch
-
Output:
-
electric current
-
Material:
-
Wack silicon
-
Color:
-
black or customized
-
Dimension:
-
35mm*34mm
-
Application:
-
for revolving door, industrial doors, or gates
-
Required force:
-
<20N
-
Temperature range:
-
-35℃~+80℃
-
Weight:
-
560g/m
-
Packing:
-
carton,30 m/roll
-
Launch distance:
-
2.7mm
Quick Details
-
Usage:
-
Rebound in case of obstacles
-
Series:
-
Integrated safety edge
-
Features:
-
Safety edge switch system
-
Mounting Type:
-
Screw to fix by the aluminum rail
-
Description:
-
Integrated rubber safety edge, Safety edge sensor
-
Model Number:
-
FA-108
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
FT
-
Theory:
-
Anti-clip Anti-collision Anti-pinch
-
Output:
-
electric current
-
Material:
-
Wack silicon
-
Color:
-
black or customized
-
Dimension:
-
35mm*34mm
-
Application:
-
for revolving door, industrial doors, or gates
-
Required force:
-
<20N
-
Temperature range:
-
-35℃~+80℃
-
Weight:
-
560g/m
-
Packing:
-
carton,30 m/roll
-
Launch distance:
-
2.7mm
FA-108 Wacker silicone material for automatic sliding gates,scissor lifts,sectional doors,door shelters, A utomatic gate&barriers,automatic folling shutters,high speed doors,dock levellers,high speed sprial doors.
· With bottom bar safety edge (to prevent door closing when obstructions occur)
APPLICATIONS:Installation on auto production equipments,subway auto door,adjustable bed,Automatic weeding machine,Automatic lifting platform,Robot arm...
Technical data:
| 1. Product Name | integrated safety edge |
| 2. Item | FA-108 |
| 3. Material | Wack silicon |
| 4. Color | black |
| 5. Dimension | 35*34/38mm |
| 6. Application |
for any automitic equipments |
| 7. Mounting | Aluminum track |
| 8. Resistance | <150 ohm |
| 9.Connection cable | standard length 250mm |
| 24AWG | |
| PVC,Φ3.5 mm, 2x0.23 mm | |
| UL certified | |
| 10. Tigger force | ≤30N |
| 11. Launch distance | 1.0-2.0mm |
| 12. Electric rating | Voltage: 30V DC Max. |
| Current: 0.25AMP Max. | |
| 14. Minimum bending radius | (R50mm -R1000mm) |
| 15. Working temperature | 35 ℃ ~+85 ℃ |
| 16. Storage temperature | 20 ℃ ~+60 ℃ |
| 17. Custom Design | OEM & ODM |
| 18. Weight | ± 560 g/m |
| 19. Packing | 30m/roll |
| 20. MOQ | 500m |
As customers requirment
By air or by sea
1. Trade terms: FOB, CIF, EXW, Etc.
2 . Delivery method: Express, Shipping, Airlines
3 . Payment terms: T/T, L/C, Western Union, P ayP al
4. Custom service
5. S ample service
1. Why choose us?
P rofessional---We have been engaged in these products more than 13years, and all our products are with strict quality requirements ;
2.
What is a
FUTAI Safety
Edge?
FUTAI Safety
Edge
is a touch sensitive switch that sends a signal to start, stop or reverse a motor
, and the
applications are
widely.
3.
Where can
FUTAI Safety
Edges be used?
Anywhere that you want a simple touch to send a signal!
4. Do you have the matched accessories?
Yes . W e offer One-Stop Solution service and supply the relate d accessories. But we suggest that you could get big size tracks from your own place because the delivery cost would be a little high
5.
How can I get a sample to check your quality?
After price confirmation,you can require for samples to check our quality
If you just need a blank sample to check the quality,we will provide you sample for free,
as long as you afford the sample freight
If you need printed samples,
we will charge you only the real sample making cost
.
No matter what,If further information is necessary,we will be glad to comply.
