Quick Details
-
Size:
-
4960*4840*1960mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Sea-lion
-
Power:
-
7.35KW
-
Name:
-
Ironer
-
Function:
-
Bed-sheets Drying
-
Description:
-
Laundry Ironer Machine
-
Heating:
-
Steam Heating
-
Voltage:
-
customized
-
Material:
-
Stainless Steel
-
Installation:
-
Installed
-
Operation:
-
Auotmatic
-
Used for:
-
Bed Sheets Ironing
-
Usage:
-
Industrial Usage
Quick Details
-
Warranty:
-
1 Year
-
After-sales Service Provided:
-
Video technical support, Free spare parts, Online support
-
Weight:
-
14750KG
-
Size:
-
4960*4840*1960mm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Sea-lion
-
Power:
-
7.35KW
-
Name:
-
Ironer
-
Function:
-
Bed-sheets Drying
-
Description:
-
Laundry Ironer Machine
-
Heating:
-
Steam Heating
-
Voltage:
-
customized
-
Material:
-
Stainless Steel
-
Installation:
-
Installed
-
Operation:
-
Auotmatic
-
Used for:
-
Bed Sheets Ironing
-
Usage:
-
Industrial Usage
1. The roll is made of high-quality carbon steel, whose heat conduction is 2.5 times better than that of stainless steel.
2. Serpentine design makes the linen wrapping angle up to 270 degrees, which significantly improves the ironing performance.
3. The wall thickness of the roll reaches 11 mm, which ensures large heat storage and even heating.
4. A safety valve is installed at the steam inlet and will stop the steam supply automatically when the steam pressure is higher than the safety value.
5. Thermal insulation design at both ends of rolls and all the steam pipes can reduce steam consumption by 5%.
6. Steam pressure is adjustable to prevent excessive ironing and reduce the waste of steam.
Main Parameter
| Description | YZSVI-3400(705) | |
| Rated power | kW | 7.7 |
| Wire diameter | mm | 6 |
| Hourly power consumption | kw.h | 6.2 |
| Compressed air pressure | Mpa | 0.4-0.6 |
| Compressed air inlet diameter | mm | 8 |
| Compressed air consumption | L/min | 6 |
| Steam pressure | Mpa | 0.6-0.8 |
| Steam pipe diameter | DN | 50 |
| Steam consumption | kg/h | 590 |
| Drainage pipe diameter | DN | 40 |
| Ironing speed | m/min | 0-50 |
| Working width | mm | ≤3400 |
| Ironing roll | mm | 705/3420 |
| Dimension | mm | 4960*4840*1960 |
| Weight | kg | 17100 |
Jiangsu Sea-lion Machinery Co., Ltd. is the oldest manufacturer of industrial laundry machines in China possessing a wealth of experience in manufacturing from years of research and development. The Sea-lion factory campus in Zhangjiagang is an impressive vertically integrated design and production facility with a building area of 166,000 SQM and total assets of 520 million RMB.
Sea-lion has the largest product range and most comprehensive variety of laundry machinery in China, including 10 series, 20 varieties and more than 100 types with annual production capacity of 15,000 machines. Sea-lion’s annual sales volume has risen to over 600 million RMB with sales to over 90 countries and territories.
In a world of seemingly unsurmountable challenges, Sea-lion’s perseverance will continue to bring success. Over the past 50 years, Sea-lion is in the era of revolution with many opportunities and challenges. Sea-lion is willing to work together with friends from all sectors of the world to create a better tomorrow by sincere cooperation, win-win development and construction. We believe that we can revitalize the national industry and climb the world peak.
Together, we create a clean world!
