Quick Details
-
Memory Type:
-
DDR4
-
Graphics Card Type:
-
Integrated
-
Chipset:
-
Intel 3865U, Intel 3865U
-
FSB / HT:
-
1.80 GHz
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
Model NO.:
-
ZA-3865AC1
-
Size:
-
Mini ITX170mm x 170mm
-
CPU:
-
Intel Celeron 3865U 1.80 GHz Processor
-
Memory:
-
1*DDR4 Slot ,2133 MHz,Up to 16GB
-
Graphics:
-
Intel HD Graphics
-
BIOS:
-
AMIBIOS,64M bit Flash Memory
-
Expansion Slots:
-
1* MINI-PCIE (Support mSATA), 1* MINI-PCIE (Support WIFI 3G)
-
Operating System:
-
Windows7, Windows8, Windows10,/Linux
-
Display:
-
Support VGA/HD/LVDS
Quick Details
-
Maximum Ram Capacity:
-
16GB
-
Application:
-
Digital Signage
-
Form Factor:
-
Mini-ITX
-
Memory Type:
-
DDR4
-
Graphics Card Type:
-
Integrated
-
Chipset:
-
Intel 3865U, Intel 3865U
-
FSB / HT:
-
1.80 GHz
-
Brand Name:
-
OEM
-
Place of Origin:
-
Guangdong, China
-
Model NO.:
-
ZA-3865AC1
-
Size:
-
Mini ITX170mm x 170mm
-
CPU:
-
Intel Celeron 3865U 1.80 GHz Processor
-
Memory:
-
1*DDR4 Slot ,2133 MHz,Up to 16GB
-
Graphics:
-
Intel HD Graphics
-
BIOS:
-
AMIBIOS,64M bit Flash Memory
-
Expansion Slots:
-
1* MINI-PCIE (Support mSATA), 1* MINI-PCIE (Support WIFI 3G)
-
Operating System:
-
Windows7, Windows8, Windows10,/Linux
-
Display:
-
Support VGA/HD/LVDS
- Support Intel Celeron 3865U 1.80 GHz Processor .
- Onboard Intel 3865 U Chipset.
- Intel® HD Graphics
- Support VGA/HD/LVDS Display.
- DC_IN 12VC Input power.
|
Model NO. |
ZA-3865AC1 |
|
Size |
MINI-ITX 170mm x 170mm |
|
CPU |
Intel Celeron 3865U 1.80 GHz Processor |
|
Memory |
1*DDR4 Slot ,2133 MHz,Up to 16GB |
|
Graphics |
Intel ® HD Graphics |
|
Chipset |
Intel ® 3865U |
|
Rear I/O |
1* DC Power Input (12V) |
|
1* HD |
|
|
1* VGA |
|
|
4* USB 3.0 |
|
|
1* LAN |
|
|
1* Mic-in/Line-out |
|
|
Internal I/O |
2* USB PIN,Support 3* USB2. 0 |
|
1* CPU Fan |
|
|
1* SYS Fan |
|
|
1-6 Group Serial Port PIN |
|
|
1*LVDS PIN Support Dual Channel 8 Bit |
|
|
1*2*2 PIN Power Socket |
|
|
1*LCD Inverter |
|
|
1*LCD Backlight Control Port |
|
|
1*VGA PIN Port |
|
|
1*SATA |
|
|
1*Front panel |
|
|
1*Audio Pin Port(2W/CH) |
|
|
Expansion Slot |
1* WIFI,1* MSATA, 1*TSIM, 1* M.2 Slot |
|
BIOS |
AMIBIOS,64M bit Flash Memory |
|
LAN |
Realtek 8111E,10/100/1000 |
|
H/W Monitoring |
Temperature Management ,Voltage Management , System Power Management |
|
Audio |
ALC662 Dual Channel Output |
|
Operating System |
Windows7, Windows 8, Windows 10, Linux |
|
Temp. |
-10° C ~ 55° C |
|
Humidity |
0% ~ 95% (Relative Humidity ,No Condensation) |
Original factory package
In anti-static bag + air bubble +paper box
Customized package
Delivery Time:
1 working day to confirm our stock.
3 working days for testing and shipping.
Customized product delivery negotiation via email.
Shipping Ways:
It will be shipped by DHL/Fedex/TNT/UPS/EMS or other ways.Please contact us and choose the best one.
All products will be strictly tested by QC department and shipped worldwide directly by sea,air and express.
We will provide all document you need to import.
Q: Why choose us?
A: 1.Professional embedded motherboard manufacturer for years with great experience.
2.Own factory and independent research, you can share directly with factory price.
3.Provode OEM/ODM service.
4. CE,FCC,ISO9001/14001 RoHs etc certificated,quality guaranteed.
Q: What is the time of delivery?
A: It depend on your quantity and production schedule.Usually,1-3 working days for sample order,
10-20 working days for mass production after receiving payment.
Q: What kind of payment do you accepet?
A: T/T,West union,Paypal,Visa,E-checking etc.
Q: How is your warranty policy for goods?
A: We focus on after-services,and all our products share 3 years warranty.
