Quick Details
-
Power:
-
0kw
-
Min. Lifting Height:
-
500mm
-
Table Size:
-
1200*610*80mm
-
Overall Dimensions:
-
1250*660*230mm
-
Weight:
-
280 kg
-
Product name:
-
hydraulic lift table
-
Model:
-
PTS1500
-
Min. height:
-
500mm
-
Max. height:
-
1700mm
-
Net Weight:
-
280kg
-
Packing Size:
-
1250*660*230mm
-
Capacity:
-
1500kg
-
Platform size:
-
1200*610mm
-
Scissor:
-
Double Scissor
-
Color:
-
As per request
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
WEMALIFT
-
Power:
-
0kw
-
Min. Lifting Height:
-
500mm
-
Table Size:
-
1200*610*80mm
-
Overall Dimensions:
-
1250*660*230mm
-
Weight:
-
280 kg
-
Product name:
-
hydraulic lift table
-
Model:
-
PTS1500
-
Min. height:
-
500mm
-
Max. height:
-
1700mm
-
Net Weight:
-
280kg
-
Packing Size:
-
1250*660*230mm
-
Capacity:
-
1500kg
-
Platform size:
-
1200*610mm
-
Scissor:
-
Double Scissor
-
Color:
-
As per request
Recommend Products
Product Description
Single scissor manual lift table
Different capacity, material, table size, lifting height to meet your need.
Option of folded handle.
*Standard with PU wheels
*Reliable hydraulic pump, long service life
*Designed to prevent pinching
*The use of hight-quality pump and drive wheels makes the cargo lift stable and powerful. Meet EN157 standard.
Specification
|
Model
|
PT150
|
PT300
|
PT500
|
PT800
|
PT1000
|
PT1500
|
PT2000
|
||||||
|
Load capacity(kg)
|
150
|
300
|
500
|
800
|
1000
|
1500
|
2000
|
||||||
|
Min. height(mm)
|
210
|
280
|
280
|
415
|
415
|
380
|
380
|
||||||
|
Max. height(mm)
|
720
|
900
|
900
|
1000
|
1000
|
1000
|
1000
|
||||||
|
Table dimension(mm)
|
700x450x35
|
815x500x50
|
815x500x50
|
1016*510*60
|
1016*510*60
|
1200*610*80
|
1200*610*80
|
||||||
|
Dia. of the wheel(mm)
|
100
|
125
|
125
|
150
|
150
|
150
|
150
|
||||||
|
Net weight(kg)
|
42
|
74
|
77
|
99
|
99
|
177
|
177
|
||||||
|
Packing size(mm)
|
820x470x230
|
900x510x310
|
900x510x310
|
1140*570*425
|
1140*570*425
|
1370*620*390
|
1370*620*39
|
||||||
|
Load in 20ft container(pcs)
|
192
|
144
|
144
|
80
|
80
|
65
|
65
|
||||||
|
Color
|
Yellow, can be customized
|
|
|
|
|
|
|
||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
