Quick Details
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DE-13W/CY
Quick Details
-
Warranty:
-
2 years
-
Application:
-
Outdoor, Hotel, Garage, Commercial, Household
-
Power Source:
-
Electric
-
Type:
-
Air Source Heat Pump
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
DE-13W/CY
Product description:
a.Suitable for outdoor or indoor installation with good ventilation.
b.R410A or R290 gas for option.
c.PVC shell titanium condenser that can stand for 45 degree max. pool temp.
d.Metal cabinet.
1.Heat pump specification:
|
Model |
DE-13W/CY |
|
Power supply(V/ph/Hz) |
220/1/50 |
|
Heating capacity(kw) |
5.2 |
|
power input(kw) |
1.06 |
|
Refrigerant |
R410A/ R290 |
|
Max.current(A) |
9.5 |
|
Rated water temp. (℃) |
28 |
|
Level against electric shock |
I |
|
Water-proof grade |
IPX4 |
|
Net weight(kg) |
58 |
|
Net size(mm) |
1005*350*620 |
|
Required water flow rate(m3/h) |
2 |
|
Water connection |
50mm |
|
Operation temp.range (℃) |
-10-45 |
|
Noise dB(A) |
≤ 42 |
|
Test condition |
Ambient temp.(DB/WB):26
℃
/15
℃
|
2.Heat pump main components used:
a. Panasonic rotarry compressor.
b. Emerson thermal expansion valve.
c. Saginomiya 4-way valve.
d. Emerson dryer filter.
3.Heat pump dimension:
4.Other information:
a. The heat pump delivery time is within 25 to 30 working days after deposit payment.
b. Packing type: Ply-wood box.
c. Warranty start from the heat pump arrive destination port.
5.Install scheme:
6.Portable install:
Our factory been producing heat pump since 2005, provide flexiable ODM service.
