Quick Details
-
Positioning Accuracy (mm):
-
0.01 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.01 mm
-
Spindle Motor Power(kW):
-
3.5
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Grandio
-
Voltage:
-
380V, 380V Optional 220V
-
Power (kW):
-
3.5
-
Weight (KG):
-
1800
-
Product name:
-
stone wood marble granite engraving machine
-
Application:
-
Stone wood Marble Granite Quartz Sandstone
-
Power:
-
7.5KW
-
Control system:
-
DSP/MACH 3/NC STUDIO
-
Cutting materials:
-
Stone wood Marble Granite Tile
-
Feature:
-
5 Axis Cnc Stone wood Carving Machine
-
Blade diameter:
-
300~350mm
-
Spindle power:
-
7.5kw Mechanical Spindle
-
Main motor power:
-
7/9kw
Quick Details
-
Working Table Size(mm):
-
2000×4000
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
0 - 48000 rpm
-
Positioning Accuracy (mm):
-
0.01 mm
-
Travel (X Axis)(mm):
-
1300 mm
-
Travel (Y Axis)(mm):
-
2500 mm
-
Repeatability (X/Y/Z) (mm):
-
0.01 mm
-
Spindle Motor Power(kW):
-
3.5
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Grandio
-
Voltage:
-
380V, 380V Optional 220V
-
Power (kW):
-
3.5
-
Weight (KG):
-
1800
-
Product name:
-
stone wood marble granite engraving machine
-
Application:
-
Stone wood Marble Granite Quartz Sandstone
-
Power:
-
7.5KW
-
Control system:
-
DSP/MACH 3/NC STUDIO
-
Cutting materials:
-
Stone wood Marble Granite Tile
-
Feature:
-
5 Axis Cnc Stone wood Carving Machine
-
Blade diameter:
-
300~350mm
-
Spindle power:
-
7.5kw Mechanical Spindle
-
Main motor power:
-
7/9kw
Product Description
Machine Features
The machine is also called: cylinder engraving machine, dragon column engraving machine, Roman column engraving machine, cylinder relief engraving machine.
1.
The machine body is constructed from the rear wall steel pipe. A rigid and stable machining platform is provided for the machine tool, and all machine bed components are stress relieved before machine bed machining. Equipped with imported guide rail, lead screw
2.
The embedded DSP numerical control system using USB transmission can realize continuous engraving at breakpoints, power-off memory function, and standard flash memory, which can realize complete offline operation, and can also use NCSTUDL operating system.
3.
The processing speed is fast and the efficiency is high, and the flight attendant speed can reach 10000mm/min. Gantry type movement, durable, long-term use without deformation, so that the positioning accuracy is more accurate.
|
Model
|
1325 economical
|
1325 heavy duty
|
|
|
Table Size
|
1300*2500mm
|
1300x2500mm
|
|
|
Feeding Height(Z Axis)
|
200mm
|
200mm
|
|
|
Table
|
aluminum+pvc
|
vacuum table
|
|
|
Spindle Power
|
4.5kw water cooled spindle
|
5.5kw spindle
|
|
|
Spindle Speed
|
0-2400rpm
|
0-24000rpm
|
|
|
Spindle
|
1
|
1
|
|
|
Frequency converter
|
Best
|
Best
|
|
|
Oil System
|
auto-oil
|
auto oil
|
|
|
Max Travelling Speed
|
8000mm/min
|
8000mm/min
|
|
|
Guide Rail
|
20 guide rail
|
20mm guide rail
|
|
|
Driving Mode
|
stepper motor
|
stepper motor
|
|
|
control
|
NC studio control
|
|
|
Vacuum adsorption table
Rotation axis
DSP control system
4.5KW HQD water cooling spindle
Hiwan guide rail
Fuling inverter
Sample
The appearance, function and size of all our machines can be customized.
The overall price is affected by the function configuration, the price is for reference only, please contact customer service for the specific price.
services
Pre-Sales Service
1.We have many exhibitions very year, hundreds of clients was coming to our booth for further communication.
2. 24-hours online Inquiry and consulting support.
3.Support sample testing .
4.We welcome you to visit our factory.
After-Sales Service
1. Training how to install the machine, training how to use the machine online.
2.Engineers available to clients' factory for training if necessary.
3.Guarantee for one year
4.24-hour technical support by email or calling
5.User-friendly English manual for machine using and maintaining
6.Free technician training for customers.
Packing & Delivery
The wooden box is sealed and packaged for safe transportation and effectively prevent bumps.
Because the machinery is relatively heavy, shipping is generally chosen.
Shipping and payment methods can be negotiated with customer service.
