Quick Details
-
Brand Name:
-
JuGuan
-
Model Number:
-
JGLWQ
-
Medium:
-
Gas
-
Accuracy:
-
1.5%
-
Size:
-
DN25~DN300
-
Connection mode:
-
Flange connection and threaded connection
-
Material:
-
304 Stainless Steel
-
Medium temperature:
-
-30°C~+80°C
-
Class of protection:
-
IP65/IP68
-
Display:
-
YES
-
Output:
-
RS485,4~20mA
-
Atmospheric pressure:
-
86~106KPa
Quick Details
-
Type:
-
Variable Area Air & Gas Flowmeters
-
Warranty:
-
12month
-
Place of Origin:
-
shanghai
-
Brand Name:
-
JuGuan
-
Model Number:
-
JGLWQ
-
Medium:
-
Gas
-
Accuracy:
-
1.5%
-
Size:
-
DN25~DN300
-
Connection mode:
-
Flange connection and threaded connection
-
Material:
-
304 Stainless Steel
-
Medium temperature:
-
-30°C~+80°C
-
Class of protection:
-
IP65/IP68
-
Display:
-
YES
-
Output:
-
RS485,4~20mA
-
Atmospheric pressure:
-
86~106KPa
Product Description
Product characteristics
1: High quality aluminum alloy turbine, with higher flow stability and corrosion resistance
2: Imported high quality special bearings, long service life
3: The measuring room is isolated from the ventilation room to ensure the safety of the instrument
4: Wide flow range (Qmax/Qmin≥ 20:1), good repeatability, high accuracy (up to 0.75%), small pressure loss, low starting flow, up to 0.63m³/h
5: Instrument has explosion-proof and protection function, explosion-proof mark is ExdllBT6,Exall CT6, protection grade is IP65/IP68
6: Can be made into insert type, suitable for large diameter measurement, low price, can not break out, easy installation and maintenance
7：
Acceptable OEM,ODM,OBM customization，Contact me directly clicking here！
Specification
|
Warranty
|
12month
|
|
Customized support
|
OEM, ODM, OBM, Software reengineering
|
|
Place of Origin
|
shanghai
|
|
Brand Name
|
JIANT
|
|
Type
|
Variable Area Air & Gas Flowmeters
|
|
Medium
|
Gas
|
|
Accuracy
|
1.5%
|
|
Size
|
DN25~DN300
|
|
Connection mode
|
Flange connection and threaded connection
|
|
Material
|
304 Stainless Steel
|
|
Medium temperature
|
-30°C~+80°C
|
|
Class of protection
|
IP65/IP68
|
|
Display
|
YES
|
|
Output
|
RS485,4~20mA
|
|
Atmospheric pressure
|
86~106KPa
|
