Quick Details
-
Warranty:
-
1year
-
Place of Origin:
-
FUJ
-
Brand Name:
-
minchuan
-
Model Number:
-
HX-30
-
Speed:
-
1500 rmp / 1800 rmp
-
Weight:
-
260KG
-
Product Name:
-
Alternator Generator
-
Color:
-
Customers' Request
-
Phase:
-
1 Phase/3 Phase
-
Type:
-
AC Brushless Alternator
-
Certification:
-
CE
Quick Details
-
Rated Voltage:
-
110V-480V
-
Rated Current:
-
Depends on voltage
-
Frequency:
-
50 Hz/ 60 Hz
-
Warranty:
-
1year
-
Place of Origin:
-
FUJ
-
Brand Name:
-
minchuan
-
Model Number:
-
HX-30
-
Speed:
-
1500 rmp / 1800 rmp
-
Weight:
-
260KG
-
Product Name:
-
Alternator Generator
-
Color:
-
Customers' Request
-
Phase:
-
1 Phase/3 Phase
-
Type:
-
AC Brushless Alternator
-
Certification:
-
CE
PRODUCT FEATURES
1. Output range 6.5kw-1150kw, single-phase and three-phase
2. Three-phase four-wire, frequency 50/60Hz, speed 1500/1800rmp
3. Automatic voltage regulation, can operate in harsh environment
4. Simple installation and maintenance, easy to connect with the power grid or generator
Insulation Class B
All adjustment parts are made of special materials and lacquered by special process. Protect alternator in corrosive environment
|
ALTERNATOR
|
|
|
|
|
|
|
||||||
|
Model
|
Output
|
Output
|
voltage
|
factor
|
speed
|
topspeed
|
||||||
|
|
(KVA)
|
(KW)
|
(V)
|
(COS)
|
(R.P.M)
|
|
||||||
|
HX-6
|
8.1
|
6.5
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-8
|
11
|
8.8
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-10
|
13.5
|
10.8
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-12
|
16
|
12.8
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-18
|
22.5
|
18
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-22
|
27.5
|
22
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-25
|
31.3
|
25
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-30
|
37.5
|
30
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-40
|
50
|
40
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-50
|
72.5
|
58
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-80
|
100
|
80
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-120
|
160
|
128
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-160
|
200
|
160
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-200
|
250
|
200
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-300
|
380
|
304
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-400
|
500
|
400
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-500
|
625
|
500
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-640
|
800
|
640
|
400
|
0.8
|
1500
|
4
|
||||||
|
HX-800
|
1000
|
800
|
400
|
0.8
|
1500
|
4
|
||||||
|
Note: These are only the typical technical data for reference, other specification such as voltage, speed, output,brand of alternator,engine,controller can be customized.
|
|
|
|
|
|
|
||||||
