Quick Details
-
Structure:
-
airslide fabric
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
Shengquan
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
Customized
-
Weight (KG):
-
4 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Thickness:
-
4-8mm
-
Ply:
-
5-8 mm
-
Weight:
-
3200-4800g/m2
-
Usage:
-
Cement plant or bulk cement
-
Max Width:
-
2600mm
-
Standard or Nonstandard:
-
Standard
-
Supply Type:
-
Make-to-Order
-
Technics:
-
Woven
Quick Details
-
Power:
-
Customized
-
Warranty:
-
3 months
-
Width or Diameter:
-
Customized
-
Structure:
-
airslide fabric
-
Place of Origin:
-
Tianjin, China
-
Brand Name:
-
Shengquan
-
Voltage:
-
380V
-
Dimension(L*W*H):
-
Customized
-
Weight (KG):
-
4 kg
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Thickness:
-
4-8mm
-
Ply:
-
5-8 mm
-
Weight:
-
3200-4800g/m2
-
Usage:
-
Cement plant or bulk cement
-
Max Width:
-
2600mm
-
Standard or Nonstandard:
-
Standard
-
Supply Type:
-
Make-to-Order
-
Technics:
-
Woven
Function :
(1) They are used on pneumatic conveyors, silos of every type, vehicle trucks and ail-wagons and also in ships.
(2) Air slide Fabrics are an indispensable part of cement plan, chemical industry, metallurgical industry, bulk cement tank trucks, bulk cement ship and fixed cement tanks.
(3) Powder moves on the fluidization conveyor over air slide fabrics.
The fluidization conveyor not have power parts.
(4) Flow is achieved by an air flow through the airslide fabrics that removes friction between powder and the air-permeating textile materials .
| PRODUCT SPECIFICATION | ||||||||
| Type | Material | Ply | Tensile strength |
Thickness
(+0.8, -0.5mm) |
Weight
g/m2 |
Max
Width (mm) |
Air
Resistance in2m3/m2/min H2O/mm |
|
| Warp>N/mm | Weft>N/mm | |||||||
| AP4-4 |
100%
polyester |
4 | 360 | 270 | 4 | 3200 | 2600 |
TypeA:80-120
TypeB:120-150 TypeC150-200 |
| AP4-5 |
100%
polyester |
4 | 360 | 270 | 5 | 3600 | 2600 |
TypeA:80-120
TypeB:120-150 TypeC150-200 |
| AP4-6 |
100%
polyester |
4 | 360 | 270 | 6 | 4000 | 2600 |
TypeA:80-120
TypeB:120-150 TypeC150-200 |
| AP4-7 |
100%
polyester |
4 | 360 | 270 | 7 | 4400 | 2000 |
TypeA:80-120
TypeB:120-150 TypeC150-200 |
| AP4-8 |
100%
polyester |
4 | 360 | 270 | 8 | 4800 | 2000 |
TypeA:80-120
TypeB:120-150 TypeC150-200 |
| AC4-5 |
100%
polyester |
4 | 150 | 130 | 5 | 3800 | 1000 |
TypeA:80-120
TypeB:120-150 TypeC150-200 |
1.Are you a Manufacturer?
Shengquan New Technology Co., Ltd. specializes in the production of Air-slip fabrics (belts), and 100% of manufacturers can visit the production line.
2.What is your mainly product?
Our company mainly has six chains of products, including airslide fabric (belt), tubular fabric, solid woven conveyor belts, solid needle conveyor belts, cotton sifter pads, cotton pipes, filtration fabric and filter bags.
3.Where is the nearest shipping port to your plant factory?
We ship the goods via Tianjing Port.
4.What is the location of your company?
Our factory: Tianjin, China (Mainland)
5.Where is the mainly overseas market?
Now we already export the hose to Brazil, South africa, USA, Peru, Chile, UK, Spain, Germany, India, Indonesia, Russia, Ukraine, Saudi Arabia, U.A.E., Korea......
6.What would be your advantage?
We can supply good quality product, good price. good service, fast delivery, also our export people are more professional.
