Quick Details
-
Positioning Accuracy (mm):
-
0.01 mm
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Y Axis)(mm):
-
900 mm
-
Repeatability (X/Y/Z) (mm):
-
0.01 mm
-
Spindle Motor Power(kW):
-
9KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
QUEENCNC
-
Voltage:
-
AC380V/50HZ
-
Dimension(L*W*H):
-
2100*2200*1850mm
-
Power (kW):
-
9
-
Weight (KG):
-
1000
-
Product name:
-
cnc wood router woodworking machine
-
Control system:
-
Mach3
-
Working area:
-
600*900MM
-
Table Surface:
-
Vaccum Table
-
Guide rail:
-
Taiwan Square Linear Rail
-
Inverter:
-
Delta
-
Spindle:
-
9KW ATC
-
Driver:
-
Servo
-
Spindle speed:
-
24000RPM
-
Working Voltage:
-
220V/380V
Quick Details
-
Working Table Size(mm):
-
600*900
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
6000 - 24000 rpm
-
Positioning Accuracy (mm):
-
0.01 mm
-
Travel (X Axis)(mm):
-
600 mm
-
Travel (Y Axis)(mm):
-
900 mm
-
Repeatability (X/Y/Z) (mm):
-
0.01 mm
-
Spindle Motor Power(kW):
-
9KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
QUEENCNC
-
Voltage:
-
AC380V/50HZ
-
Dimension(L*W*H):
-
2100*2200*1850mm
-
Power (kW):
-
9
-
Weight (KG):
-
1000
-
Product name:
-
cnc wood router woodworking machine
-
Control system:
-
Mach3
-
Working area:
-
600*900MM
-
Table Surface:
-
Vaccum Table
-
Guide rail:
-
Taiwan Square Linear Rail
-
Inverter:
-
Delta
-
Spindle:
-
9KW ATC
-
Driver:
-
Servo
-
Spindle speed:
-
24000RPM
-
Working Voltage:
-
220V/380V
Product Description
Specification
|
Model (option)
|
QN6090L
|
|
X，Y，Z axis working area
|
600*900*200mm
|
|
Guide rail
|
Square guide linear rail from taiwan
|
|
X,Y structure
|
High-precision rack and pinion transmission
|
|
Z axis
|
ball screw
|
|
Control system
|
Mach3 control
|
|
Whole structure
|
Cast steel
|
|
Max.engraving speed
|
40m/min
|
|
Maxing cutting speed
|
25m/min
|
|
Resolution
|
0.01mm
|
|
Processing accuracy
|
<0.05mm
|
|
Wood holding
|
Vacuum absorption(by suction)
|
|
Competitive software
|
AutoCAD,Artcam,Photoshop,Type3,Artcut,Ucancam,powermill
|
|
Imagine format graphic
|
BMP,GIF,JPGE,PCX,TGA,TIFF,PTLCDR,DMG,DXF
|
|
Spindle power (you can choose)
|
9KW ATC spindle
|
|
Spindle rotating speed
|
6000-24000rmp/min
|
|
Tool magazine
|
8 pieces of cutters
|
|
Diameter of cutter
|
φ3.175~φ20
|
|
Driving system
|
servo system
|
|
Operate language
|
G code,plt,mmg,uoo,bmp,F/S
|
|
Working voltage
|
AC380V/50Hz
|
|
Running environment
|
Temperature:0-45;Humidity:30%~70%
|
|
With Optional parts
|
Vacuum worktable
|
|
Machine parts
|
9kw atc water cooled spindle
servo motor and driver
Mach3control system
Taiwan 20 squarer guide rail inverter equipment vacuum pump and vacuum worktable(7.5kw vacuum pump) oil lubricating system automatic tool measurement8
tool holder and collets
Dust collector 5.5KW control box/wrench/brush user manual /CD video/design software |
