80KW high quality inboard electric boat motor 10-40 knots conversion kit AC marine boat engine

80KW high quality inboard electric boat motor 10-40 knots conversion kit AC marine boat engine

FOB Reference Price: Get Latest Price

≥1 Sets

US $20000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Model Number:: RSEBK1.0

Frequency:: 200Hz

motor no.:: RSTM262D1-H

Battery voltage:: 540VDC

Rated Power:: 50kw

Peak Power:: 80kw

Rated Torque:: 170Nm

Peak Torque:: 380Nm

Rated Speed:: 3000rpm

Peak Speed:: 6000rpm

customized service:: available

System testing service:: available

Certification:: ce

Quick Details

AC Voltage:: 284VAC

Place of Origin:: Guangdong, China

Brand Name:: rawsuns

Model Number:: RSEBK1.0

Frequency:: 200Hz

motor no.:: RSTM262D1-H

Battery voltage:: 540VDC

Rated Power:: 50kw

Peak Power:: 80kw

Rated Torque:: 170Nm

Peak Torque:: 380Nm

Rated Speed:: 3000rpm

Peak Speed:: 6000rpm

customized service:: available

System testing service:: available

Certification:: ce

Product Description

Product Description

Rawsun EV motor

Rawsun EV motor

Contact me for more options!

Rawsun ev motors are high efficiency designed for electric vehicles and electric boats as drive engines with output peak power 50 kw to 200 kw, peak torque 180 Nm to 2800 Nm.

When you do not have specific motor parameters, please contact me to get and fill in a

Vehicle technical information demand list, we will calculate the motor requirements for you

and recommend or develop again according to your needs.

Model	Applications	Battery Voltage	Motor Rated KW	Motor Peak KW	Tmin /N.m	Tmax /N.m	Speedmin /rpm	Speedmax /rpm	Imin /A	Imax /A
RSTM260-J	2T Truck	380	25	50	80	180	3000	6000	82	190
RSTM261-J	2.5T Truck	380	34	68	110	270	3000	6000	110	320
RSTM262-J	4.5T Truck / 6M AMT Bus	380	50	90	160	350	3000	6000	140	300
RSTM262D1	5T Truck	380	50	80	170	380	2800	6000	171	325
RSTM262D1-H	5T Truck	540	50	80	170	380	3000	6000	129	278
RSTM423	8M AMT Bus	540	70	120	335	600	2000	4500	165	295
RSTM424	8M AMT Bus	380	70	120	335	600	2000	4500	210	370
RSTM424A	10 AMT Bus	540	90	130	285	500	3000	4500	170	300
RSTM420	6.6-7M Direct-drive Bus/ 7.5T Truck	540	115	150	550	1000	2000	4500	200	350
RSTM421	6M Direct-drive	380	70	120	335	800	2000	4500	163	374
RSTM422	10-12M AMT Bus	540	115	150	550	1000	2000	4500	200	350
RSTM430	8M Direct-drive Bus	540	92	140	764	1700	1150	3000	160	350
RSTM460A-2500	12M Direct -drive	576	100	200	1000	2500	955	2700	210	500
RSTM460A-2800	12M Direct -drive	576	120	200	1200	2800	955	2700	240	543
