Quick Details
-
Certification:
-
CE & ISO
-
Beam Transmission:
-
Biquartz optical fiber transmission
-
Laser Type:
-
CW, pulse, single
-
Wavelength:
-
978nm±2nm 1470nm±2nm
-
Fiber:
-
400/600/800um
-
Power:
-
1-60W
-
Pulse width:
-
0.01-1s (stepping 0.05s)
-
Pulse delay:
-
0.01-1s (stepping 0.05s)
-
Certification 1:
-
ce
-
Certification 2:
-
ISO13485
Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
Sunrise
-
Model Number:
-
980nm 1470n Diode laser
-
Certification:
-
CE & ISO
-
Beam Transmission:
-
Biquartz optical fiber transmission
-
Laser Type:
-
CW, pulse, single
-
Wavelength:
-
978nm±2nm 1470nm±2nm
-
Fiber:
-
400/600/800um
-
Power:
-
1-60W
-
Pulse width:
-
0.01-1s (stepping 0.05s)
-
Pulse delay:
-
0.01-1s (stepping 0.05s)
-
Certification 1:
-
ce
-
Certification 2:
-
ISO13485
Working Principle
The 1470nm wavelength has a high degree of water absorption in the tissue,and 980 nm provides high absorption in hemoglobin.
The irreversible photo-thermal process induced by the laser energy results in a complete occlusion of the treated vein. The lower
energy level needed using the radial laser fiber significantly minimized adverse effects compared with the bare laser fiber.
The irreversible photo-thermal process induced by the laser energy results in a complete occlusion of the treated vein. The lower
energy level needed using the radial laser fiber significantly minimized adverse effects compared with the bare laser fiber.
Technical Parameter
|
Input voltage
|
220V-50HZ/110V-60HZ 5A
|
|
Power
|
1-60W
|
|
Wavelength
|
980nm 1470nm
|
|
Frequency
|
1-5hz
|
|
Pulse width
|
1-200ms
|
|
Output mode
|
fiber
|
|
Touch screen
|
8 Inch
|
|
Aiming Beam
|
650nm
|
|
Mode
|
Pulse mode, Continuous mode
|
|
Length fiber
|
2mm
|
|
Cooling
|
air cooling
|
|
Control Panel
|
Touch Button Control Panel
|
|
Focus Size
|
0.2/ 0.5/1.0/2.0/ 3.0mm
|
|
Machine Dimension
|
36*34*32cm
|
|
Gross weight
|
18kg
|
Basic Function
Mainly for vascular therapy:
1 EVLT (Endovenous Veins Laser Treatment)
2 Vascular lesion therapy
3 Spider Veins/face veins
Remove red blood: all kinds of telangiectasia, cherry haemangioma etc.
Other therapy:
1 Skin protrusions: warts, mole, flat warts, compound nevus, junctional nevus, fat particles and other skin problems;
2 Pigmented lesions: age spots, sunburn, pigments,
3 Plastic surgery: Lipolysis
4 ENT
5 Dental
6 Gynecological
1 EVLT (Endovenous Veins Laser Treatment)
2 Vascular lesion therapy
3 Spider Veins/face veins
Remove red blood: all kinds of telangiectasia, cherry haemangioma etc.
Other therapy:
1 Skin protrusions: warts, mole, flat warts, compound nevus, junctional nevus, fat particles and other skin problems;
2 Pigmented lesions: age spots, sunburn, pigments,
3 Plastic surgery: Lipolysis
4 ENT
5 Dental
6 Gynecological
Hemorrhoids
Minimally-invasive laser hemorrhoid surgery that effectively delivers fast relief and eliminates painful symptoms.
Usually performed as an outpatient procedure, your surgeon will direct a beam of laser energy onto each individual hemorrhoid.
The laser energy cuts off the hemorrhoid and removes it completely. The advantage of using a laser, rather than a scalpel, for this cutting is that lasers instantly close the incision and coagulate the blood, eliminating bleeding. After we’ve removed the hemorrhoids, we thoroughly clean and sterilize the area.
You should not feel any pain whatsoever during this procedure. We use a combination of local anesthesia and sedation to preclude any pain and to relax the patient.
