Quick Details
-
Brand Name:
-
Kinson
-
Model Number:
-
JS
-
Application:
-
Electric Cable Wire Protection
-
Certificated:
-
ISO9001:2008
-
Size:
-
3/8" - 6"
-
Surface:
-
Hot Dipped Glavanized
-
Structure:
-
Squarelock
-
Feature:
-
Flexibility Surface Gloss
-
Package:
-
PE warp film
-
Property:
-
Excellent bend ability
-
Color:
-
Silver metal color
Quick Details
-
Type:
-
Flexible
-
Material:
-
Other
-
Place of Origin:
-
China
-
Brand Name:
-
Kinson
-
Model Number:
-
JS
-
Application:
-
Electric Cable Wire Protection
-
Certificated:
-
ISO9001:2008
-
Size:
-
3/8" - 6"
-
Surface:
-
Hot Dipped Glavanized
-
Structure:
-
Squarelock
-
Feature:
-
Flexibility Surface Gloss
-
Package:
-
PE warp film
-
Property:
-
Excellent bend ability
-
Color:
-
Silver metal color
Flexible Metal Galvanized Steel Pipe
Material: (inner layer) adopting galvanized steel band with special insulation treatment (outer layer) adopting PVC raw material (anti-UV, anti-aging) Color: Metal.
Working temperature: -10℃ ~ +80 ℃
Certification acquired: European Environmental Protection Certification
SGS: SH6134468/CHEM
Application: Used for wire protection at railways, engines, traffic system engineering, air-conditioners, various machineries, automatic controlling equipment, power plants, chemical industries, power distribution system, communication system, vessels, mansions, factory buildings as well as the outdoors' exposed locations.
Usage: protecting wires/cables and provide insulation, waterproofing as well as beautiful outlook of the wiring.
How to use: Put the wires/cables through the pipes before fitting correspondent type of LNE-DPJ joints.
|
Item No. |
Specifications |
Outer diameter and tolerance |
Natural curve |
Max.axial pull |
Packaging unit(meter) |
|
|
Metric |
G system |
|||||
|
JS-JSH-6 |
ø6 |
3/16 ’’ |
8.2± 0.25 |
40 |
336 |
200 |
|
JS-JSH-8 |
ø8 |
1/4 ’’ |
11.0± 0.30 |
45 |
470 |
200 |
|
JS-JSH-10 |
ø10 |
5/16 ’’ |
13.5± 0.30 |
55 |
590 |
100 |
|
JS-JSH-12 |
ø12 |
- |
15.5± 0.35 |
60 |
710 |
100 |
|
JS-JSH-13 |
ø13 |
3/8 ’’ |
16.5± 0.35 |
65 |
765 |
100 |
|
JS-JSH-15 |
ø15 |
- |
19.0± 0.35 |
80 |
885 |
100 |
|
JS-JSH-16 |
ø16 |
1/2 ’’ |
20.0± 0.35 |
85 |
940 |
100 |
|
JS-JSH-19 |
ø19 |
- |
23.3± 0.40 |
95 |
1120 |
50 |
|
JS-JSH-20 |
ø20 |
3/4 ’’ |
24.3± 0.40 |
100 |
1180 |
50 |
|
JS-JSH-25 |
ø25 |
1 ’’ |
30.3± 0.45 |
120 |
1450 |
50 |
|
JS-JSH-32 |
ø32 |
1 1/4 ’’ |
38.0± 0.50 |
150 |
1885 |
25 |
|
JS-JSH-38 |
ø38 |
1 1/2 ’’ |
45.0± 0.60 |
180 |
2240 |
25 |
|
JS-JSH-51 |
ø51 |
2 ’’ |
58.0± 1.00 |
220 |
3000 |
20 |
|
JS-JSH-64 |
ø64 |
2 1/2 ’’ |
72.5± 1.50 |
310 |
3770 |
10 |
|
JS-JSH-75 |
ø75 |
3 ’’ |
83.5± 2.00 |
350 |
4400 |
10 |
|
JS-JSH-100 |
ø100 |
4 ’’ |
108.5± 3.0 |
410 |
4700 |
10 |
|
JS-JSH-125 |
ø125 |
5 ’’ |
134.5± 4.0 |
480 |
5100 |
10 |
|
JS-JSH-150 |
ø150 |
6 ’’ |
164.5± 5.0 |
550 |
5600 |
10 |
