Quick Details
-
Model Number:
-
TTL55-5544
-
Product Name:
-
Line Array Speakers
-
Rated Power:
-
3600W
-
Components:
-
2*12"+ 10" +3*2"
-
Impedance:
-
HF: 16 Ohm
-
Use:
-
Pa System Speaker Active
-
Color:
-
Black
-
Model:
-
TTL55-5544
-
Frequency Range (Hz):
-
45Hz-500Hz
-
Power:
-
3600W
Quick Details
-
Warranty:
-
Other
-
Place of Origin:
-
China
-
Brand Name:
-
ACTPRO AUDIO
-
Model Number:
-
TTL55-5544
-
Product Name:
-
Line Array Speakers
-
Rated Power:
-
3600W
-
Components:
-
2*12"+ 10" +3*2"
-
Impedance:
-
HF: 16 Ohm
-
Use:
-
Pa System Speaker Active
-
Color:
-
Black
-
Model:
-
TTL55-5544
-
Frequency Range (Hz):
-
45Hz-500Hz
-
Power:
-
3600W
Product Description
|
Model: TTL -55
|
|
|
|
Active 3-Way Line Array System
|
|
|
|
|
|
|
|
Impedance
|
LF:16Ω MF:16Ω HF:16Ω
|
|
|
Frequency Response
|
LF:45Hz-500Hz MF:500Hz-2.2KHz HF:2.2K-20KHZ
|
|
|
Average power
|
L:900W M:200W H:180W
|
|
|
Peak power
|
L:3600W M:800W H:640W
|
|
|
Sensitivity
|
L:98dB/w/m M:97dB/w/m H: 114 dB/w/m
|
|
|
Component
|
2x12+ 10 +3x2"
|
|
|
Cabinet
|
Birch Multilayer Plywood
|
|
|
Dispersion
|
100°Hx10°V
|
|
|
MAX.SPL
|
L:128dB M:117dB H:137 dB
|
|
|
Input Interface
|
2XNL8MPR Speakon, 2 X XLR(M)+2 X XLR(F)
|
|
|
Amplifier Module
|
Built-in DSP/3 channels2 in 3 out
|
|
|
AMP Output Power
|
2x600W+ 1100w/8 ohm
|
|
|
Channel
|
3 channels
|
|
|
Built -in DSP module
|
2 in 3 out
|
|
|
Output Circuit Design
|
Class D
|
|
|
Product (HWD)
|
377(310)x550x 1020mm
|
|
|
Packing WHD
|
421x548x1087mm
|
|
|
N/W
|
60 KG
|
|
