Quick Details
-
Application:
-
Landfill, artificial lake
-
Design Style:
-
Industry
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Boyuan
-
Model Number:
-
0.5mm
-
Product Name:
-
Geomembrane
-
Size:
-
5.8*50,5.8*100
-
Specifications:
-
0.5mm,1.0mm,1.5mm,2.0mm
-
Material:
-
HDPE
-
Service:
-
24 Hours Online Service
-
Quality:
-
high-quality
Quick Details
-
Warranty:
-
More than 5 years
-
After-sale Service:
-
Online technical support, Return and Replacement, Other
-
Project Solution Capability:
-
graphic design, 3D model design, total solution for projects, Cross Categories Consolidation, Others
-
Application:
-
Landfill, artificial lake
-
Design Style:
-
Industry
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Boyuan
-
Model Number:
-
0.5mm
-
Product Name:
-
Geomembrane
-
Size:
-
5.8*50,5.8*100
-
Specifications:
-
0.5mm,1.0mm,1.5mm,2.0mm
-
Material:
-
HDPE
-
Service:
-
24 Hours Online Service
-
Quality:
-
high-quality
Product Description
|
Product Name
|
Geomembrane
|
|
Size
|
5.8*50,5.8*100
|
|
Specifications
|
0.5mm,1.0mm,1.5mm,2.0mm
|
|
Material
|
HDPE
|
|
Service
|
24 Hours Online Service
|
|
Quality
|
high-quality
|
Introduction
Our high density polyethylene (HDPE) geomembranes is very low permeability synthetic membrane liner or barrier used with any geotechnical engineering related material so as to control fluid (or gas) migration in a human-made project, structure, or system.
Geomembranes are made from relatively thin continuous polymeric sheets, but they can also be made from the impregnation of geotextiles with asphalt, elastomer or polymer sprays, or as multilayered bitumen geocomposites. Continuous polymer sheet geomembranes are, by far, the most common.
It provide an impermeable barrier against a wide range of solids and liquids. They exhibit excellent chemical and UV
resistance,impermeability, and high yield and welded seam strengths, which is widely used as the liner.(model according to the thickness of distinction, different thickness and different price) production capacity: thickness:0.1 mm -6 mm, width: 1-8 meters.
It is suitable for seepage control in special industries, and is widely used for aquaculture, seepage control, reservoirs or
sewage treatment ponds.
Geomembranes are made from relatively thin continuous polymeric sheets, but they can also be made from the impregnation of geotextiles with asphalt, elastomer or polymer sprays, or as multilayered bitumen geocomposites. Continuous polymer sheet geomembranes are, by far, the most common.
It provide an impermeable barrier against a wide range of solids and liquids. They exhibit excellent chemical and UV
resistance,impermeability, and high yield and welded seam strengths, which is widely used as the liner.(model according to the thickness of distinction, different thickness and different price) production capacity: thickness:0.1 mm -6 mm, width: 1-8 meters.
It is suitable for seepage control in special industries, and is widely used for aquaculture, seepage control, reservoirs or
sewage treatment ponds.
Applicaiton
1. Environmental protection and environmental sanitation (living landfill yard, sewage & discharge liquid treatment plant, power plant adjusting tank, industrial and hospital solid waste etc.).
2. Water conservancy (anti-seepage, leakage blockage and reinforcement of river, lake and reservoir dikes and banks, anti-seepage of canal, vertical central wall, side slope etc.).
3. Municipal projects (underground project of subway and structure, anti-seepage of plantation roof and roof garden, lining of sewage pipe etc.).
4. Mine industry (heap leaching tank, tailings disposal, bottom lining and anti-seepage of washing and selecting tank, ash yard, dissolution tank etc.).
5. Traffic facilities (reinforcement of road foundation and anti-seepage of subway and tunnel).
6. Agriculture (anti-seepage of ditch, channel, reservoir, drinking water tank, pool and irrigation system).
7. Animal husbandry(biogas Pool etc.)
8. Aquaculture (lining of intensive and plant type cultivation tank, fish pound and shrimp pool, side slope of sea cucumber ring etc.).
9. Landscape garden (man-made lake, river way, cistern, bottom lining and side slope of pool in golf course, waterproof and anti-seepage of greening lawn etc.).
10. Petrochemical industry (anti-seepage of oil tank of chemical plant, oil refinery and filling station, lining of chemical
reaction tank and sedimentation tank etc.).
11. Salt industry (crystal tank of salt field, tarpaulin cover of halogenation tank, salt film, plastic tarpaulin cover of salt
tank).
2. Water conservancy (anti-seepage, leakage blockage and reinforcement of river, lake and reservoir dikes and banks, anti-seepage of canal, vertical central wall, side slope etc.).
3. Municipal projects (underground project of subway and structure, anti-seepage of plantation roof and roof garden, lining of sewage pipe etc.).
4. Mine industry (heap leaching tank, tailings disposal, bottom lining and anti-seepage of washing and selecting tank, ash yard, dissolution tank etc.).
5. Traffic facilities (reinforcement of road foundation and anti-seepage of subway and tunnel).
6. Agriculture (anti-seepage of ditch, channel, reservoir, drinking water tank, pool and irrigation system).
7. Animal husbandry(biogas Pool etc.)
8. Aquaculture (lining of intensive and plant type cultivation tank, fish pound and shrimp pool, side slope of sea cucumber ring etc.).
9. Landscape garden (man-made lake, river way, cistern, bottom lining and side slope of pool in golf course, waterproof and anti-seepage of greening lawn etc.).
10. Petrochemical industry (anti-seepage of oil tank of chemical plant, oil refinery and filling station, lining of chemical
reaction tank and sedimentation tank etc.).
11. Salt industry (crystal tank of salt field, tarpaulin cover of halogenation tank, salt film, plastic tarpaulin cover of salt
tank).
Product Parameters
|
Thickness
|
0.75
|
1.0
|
1.25
|
1.50
|
2.00
|
2.50
|
3.00
|
|
Density g/m2
|
≥0.94
|
≥0.94
|
≥0.94
|
≥0.94
|
≥0.94
|
≥0.94
|
≥0.94
|
|
Tensile yield strength (N/mm)
|
≥11
|
≥15
|
≥18
|
≥22
|
≥29
|
≥37
|
≥44
|
|
Tensile breaking strength (N/mm)
|
≥20
|
≥27
|
≥33
|
≥40
|
≥53
|
≥67
|
≥80
|
|
Bongation at yield(%)
|
≥12
|
≥12
|
≥12
|
≥12
|
≥12
|
≥12
|
≥12
|
|
Elongation at break(%)
|
≥700
|
≥700
|
≥700
|
≥700
|
≥700
|
≥700
|
≥700
|
|
Tear resistance(N)
|
≥93
|
≥125
|
≥160
|
≥190
|
≥250
|
≥315
|
≥375
|
|
Puncture strength(N)
|
≥240
|
≥320
|
≥400
|
≥480
|
≥640
|
≥800
|
≥960
|
|
Tensile load stress cracking
|
≥300
|
≥300
|
≥300
|
≥300
|
≥300
|
≥300
|
≥300
|
|
Carbon black content(%)
|
2.0-3.0
|
2.0-3.0
|
2.0-3.0
|
2.0-3.0
|
2.0-3.0
|
2.0-3.0
|
2.0-3.0
|
