Quick Details
-
Warranty:
-
25 YEARS
-
Brand Name:
-
Gift sun
-
Model Number:
-
S-FLEX 6-365-385W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1840*1040*2.5mm
-
Cell Type:
-
Mono-crystalline
-
No. of cells:
-
126(21x6) / Mono / Half-cell
-
Weight:
-
5.7 kg
-
Encapsulant:
-
POE
-
Frame:
-
Frameless
-
Junction Box:
-
IP68 Rated
-
Cable (length/cross-section area):
-
Customizable / 4mm2
-
Connector:
-
MC4 Compatible
-
Packaging Configuration:
-
46pcs/Pallet; 1104pcs/40'HQ
-
Certificate:
-
CE TUV
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
PERC, Half Cell, MWT, Flexible
-
Panel Efficiency:
-
21.8%
-
Warranty:
-
25 YEARS
-
Brand Name:
-
Gift sun
-
Model Number:
-
S-FLEX 6-365-385W
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
1840*1040*2.5mm
-
Cell Type:
-
Mono-crystalline
-
No. of cells:
-
126(21x6) / Mono / Half-cell
-
Weight:
-
5.7 kg
-
Encapsulant:
-
POE
-
Frame:
-
Frameless
-
Junction Box:
-
IP68 Rated
-
Cable (length/cross-section area):
-
Customizable / 4mm2
-
Connector:
-
MC4 Compatible
-
Packaging Configuration:
-
46pcs/Pallet; 1104pcs/40'HQ
-
Certificate:
-
CE TUV
Products Description
Product Paramenters
Electrical Charcteristics At Standard Test Condition(STC)
STC: AM=1.5, Irradiation 1000W/m2, Module Temperature 25°C
|
Max-Power(W)
|
365
|
370
|
375
|
380
|
385
|
||||
|
Max-Power Voltage(Vm)
|
34.9
|
35.10
|
35.30
|
35.50
|
35.70
|
||||
|
Max-Power Current(lm)
|
10.46
|
10.54
|
10.62
|
10.70
|
10.78
|
||||
|
Open-Circuit Voltage(Voc)
|
42.4
|
42.60
|
42.80
|
43.00
|
43.20
|
||||
|
Short-Circuit Current(lsc)
|
11.09
|
11.16
|
11.23
|
11.30
|
11.35
|
||||
|
Module Efficiency(%)
|
20.70
|
21.00
|
21.20
|
21.50
|
21.80
|
||||
|
Power Tolerance
|
0~+5
|
|
|
|
|
||||
|
Operating Temperature(°C)
|
-40℃～+85℃
|
|
|
|
|
||||
|
Maximum system voltage
|
DC1500V(IEC)
|
|
|
|
|
||||
|
Maximum series fuse rating
|
15A
|
|
|
|
|
||||
|
Temperature coefficients of Pmax
|
-0.36%/°C
|
|
|
|
|
||||
|
Temperature coefficients of Voc
|
-0.28%/°C
|
|
|
|
|
||||
|
Temperature coefficients of Isc
|
0.06%/°C
|
|
|
|
|
||||
|
Nominal operating cell temperature(NOCT)
|
43±2°C
|
|
|
|
|
||||
