Specifications
|
|
|
|
Specifications
|
|
|
|
Rated operating capacity(kg)
|
700
|
|
|
Tipping load(kg)
|
1400
|
|
|
Bucket capacity(m3)
|
0.4-0.5
|
|
|
Operating weight(kg)
|
3000
|
|
|
Max. travel speed(km/h)
|
12
|
|
|
Hydraulic pump flow(L/min)
|
75
|
|
|
Fuel tank capacity(L)
|
70
|
|
|
Tires
|
10-16.5NHS
|
|
|
Overall dimensions(mm)
|
3350×1720×2150
|
|
|
Dimensions
|
|
|
|
Height at maximum extension(mm)
|
3980
|
|
|
Height to bucket hinge pin(mm)
|
3080
|
|
|
Width with bucket(mm)
|
1730
|
|
|
Track width(mm)
|
1450
|
|
|
Wheelbase(mm)
|
991
|
|
|
Ground clearance(mm)
|
180
|
|
|
Dump angle
|
30°
|
|
|
Dumping height(mm)
|
2380
|
|
|
Rollback at ground
|
26°
|
|
|
Angle of departure
|
20°
|
|
|
Engine
|
|
|
|
Maker/Model
|
Xinchai 490
|
|
|
Net power
|
51hp/2500rpm
|
|
|
Type
|
4 Cylinder in-line, Water cooled, 4 stroke, Diesel engine
|
|
|
Displacement(L)
|
2.7
|
|
|
Standard
|
|
|
|
Standard bucket
|
Hand control system(Mechanical type)
|
|
|
Enclosed operator cab
|
Auxiliary hydraulic couplers
|
|
|
Optional
|
|
|
|
Air conditioner
|
Preheat starting assist system for extreme cold weather
|
|
|
Cab fitted with a heater as standard
|
|
|
