Quick Details
-
Place of Origin:
-
Chongqing, China
-
Work plate Dimension [W x D]:
-
184x184mm (7 inch)
-
Work plate material:
-
Glass ceramic
-
Motor type:
-
Shaded pole motor
-
Motor rating input:
-
15W
-
Motor rating output:
-
1.5W
-
Power:
-
1030W
-
Heating output:
-
1000W
-
Voltage:
-
100-120/200-240V 50/60Hz
-
Stirring positions:
-
1
-
Max. stirring quantity, [H2O]:
-
10L
Quick Details
-
Warranty:
-
1 year
-
Brand Name:
-
Drawell
-
Model Number:
-
MS7-H550-S
-
Place of Origin:
-
Chongqing, China
-
Work plate Dimension [W x D]:
-
184x184mm (7 inch)
-
Work plate material:
-
Glass ceramic
-
Motor type:
-
Shaded pole motor
-
Motor rating input:
-
15W
-
Motor rating output:
-
1.5W
-
Power:
-
1030W
-
Heating output:
-
1000W
-
Voltage:
-
100-120/200-240V 50/60Hz
-
Stirring positions:
-
1
-
Max. stirring quantity, [H2O]:
-
10L
Details Images
Product Description
• LCD display for precise monitoring of speed and temperature
• Built-in PID controller ensures safe heating of the medium with overheating protection
• Max. heating plate temperature 550°C
• Glass ceramic work plate provides excellent chemical resistant performance and most efficient heat transfer
• External temperature control is possible by connecting the temperature sensor(PT1000) with an accuracy at ±0.2°C
• Digital speed controlling, max. speed at 1500rpm
• Outstanding brushless DC motor enables more stirring power
• Two rotating knobs enable easy adjustment of speed and temperature
• The “HOT” warning will flash when the work plate temperature is above 50°C even when the hotplate is turned off
• Remote function provides PC control and data transmission
• Built-in PID controller ensures safe heating of the medium with overheating protection
• Max. heating plate temperature 550°C
• Glass ceramic work plate provides excellent chemical resistant performance and most efficient heat transfer
• External temperature control is possible by connecting the temperature sensor(PT1000) with an accuracy at ±0.2°C
• Digital speed controlling, max. speed at 1500rpm
• Outstanding brushless DC motor enables more stirring power
• Two rotating knobs enable easy adjustment of speed and temperature
• The “HOT” warning will flash when the work plate temperature is above 50°C even when the hotplate is turned off
• Remote function provides PC control and data transmission
|
Specifications
|
MS7-H550-Pro
|
|
Work plate Dimension [W x D]
|
184x184mm (7 inch)
|
|
Work plate material
|
Glass ceramic
|
|
Motor type
|
Shaded pole motor
|
|
Motor rating input
|
15W
|
|
Motor rating output
|
1.5W
|
|
Power
|
1030W
|
|
Heating output
|
1000W
|
|
Voltage
|
100-120/200-240V 50/60Hz
|
|
Stirring positions
|
1
|
|
Max. stirring quantity, [H2O]
|
10L
|
|
Max. magnetic bar[length]
|
80mm
|
|
Speed range
|
0-1500rpm
|
|
Speed display
|
Scale
|
|
Temperature display
|
LED
|
|
Heating temperature range
|
Room temp.-550°C, increment 5°C
|
|
Temperature control accuracy
|
±10°C
|
|
Overheating protection
|
580°C
|
|
Temperature display accuracy
|
±1°C
|
|
External temperature sensor
|
PT1000 (accuracy ±0.2)
|
|
"Hot" warning
|
50°C
|
|
Protection class
|
IP21
|
|
Dimension [WxDxH]
|
215x360x112mm
|
|
Weight
|
4.5kg
|
|
Permissible ambient temperature and humidity
|
5-40°C, 80%RH
|
