- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ONEPOWER
-
Model Number:
-
OD3
-
Product Name:
-
OD3
-
Motor type:
-
brush
-
Application:
-
Solar Tracking Device
-
Noise:
-
Low Noise Level
-
Input Voltage:
-
12V/24V/36V
-
Weight:
-
5.46kg
-
Material:
-
Iron
-
Stroke:
-
100-1000mm Customized
-
Protection Class:
-
IP67
-
Limit Switch:
-
Built-in
Quick Details
-
Speed(RPM):
-
1
-
Continuous Current(A):
-
1
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
ONEPOWER
-
Model Number:
-
OD3
-
Product Name:
-
OD3
-
Motor type:
-
brush
-
Application:
-
Solar Tracking Device
-
Noise:
-
Low Noise Level
-
Input Voltage:
-
12V/24V/36V
-
Weight:
-
5.46kg
-
Material:
-
Iron
-
Stroke:
-
100-1000mm Customized
-
Protection Class:
-
IP67
-
Limit Switch:
-
Built-in
Product Description
Details Images
Construction:Iron, joint size can customized
Specification
|
Rated Voltage
|
12v 24v 36v
|
|
|
|
|||
|
Current Load
|
22A 11A 8A
|
|
|
|
|||
|
Rated Power
|
144W
|
|
|
|
|||
|
Stroke Length
|
100-----1000mm
|
|
|
|
|||
|
Max Load
|
15000N 10000N 6800N 5000N 2600N 1700N
|
|
|
|
|||
|
Speed Without Load
|
3mm/s 5mm/s 11mm/s 25mm/s 41mm/s 51mm/s
|
|
|
|
|||
|
Waterproof Grade
|
IP67
|
|
|
|
|||
|
Self-Locking Device
|
Mechanic Self-Locking Device
|
|
|
|
|||
|
Tail Mode
|
Adjustable By 30 Degrees
|
|
|
|
|||
|
Limited Device
|
Build-in Limited Switch
|
|
|
|
|||
|
Signal Feedback
|
Potentiometer ( 10K ) Hall Sensor Switch ( Optional )
|
|
|
|
|||
|
Working Temperature
|
---40℃ ---- 65℃
|
|
|
|
|||
|
Manual Operation
|
Manual Crank Manual Operation
|
|
|
|
|||
|
Working Frequency
|
10% ( Max 15%)
|
|
|
|
|||
