Quick Details
-
Model Number:
-
C1000-24P-4G-L
-
Place of Origin:
-
Beijing, China
-
Product name:
-
network Switch
-
Part Number:
-
C1000-24P-4G-L
-
Network Ports:
-
24x 1 Gigabit Ethernet PoE+ RJ-45
-
Management Ports:
-
1x RJ-45 Management, 1x USB Mini-B, 1x USB Type A
-
Switching Capacity:
-
128 Gbps
-
Forwarding Rate:
-
95.23 Mpps
-
CPU:
-
ARM v7 800 MHz
-
DRAM:
-
512 MB
-
Flash memory:
-
256 MB
-
Warranty:
-
1year
Quick Details
-
Transmission Rate:
-
10/100/1000Mbps
-
Communication Mode:
-
Full-Duplex & Half-Duplex
-
Switch Capacity:
-
128 Gbps
-
Model Number:
-
C1000-24P-4G-L
-
Place of Origin:
-
Beijing, China
-
Product name:
-
network Switch
-
Part Number:
-
C1000-24P-4G-L
-
Network Ports:
-
24x 1 Gigabit Ethernet PoE+ RJ-45
-
Management Ports:
-
1x RJ-45 Management, 1x USB Mini-B, 1x USB Type A
-
Switching Capacity:
-
128 Gbps
-
Forwarding Rate:
-
95.23 Mpps
-
CPU:
-
ARM v7 800 MHz
-
DRAM:
-
512 MB
-
Flash memory:
-
256 MB
-
Warranty:
-
1year
Products Description
C1000-24P-4G-L Overview:
Cisco® Catalyst® 1000 Series Switches are fixed managed Gigabit Ethernet enterprise-class Layer 2 switches designed for small businesses and branch offices. These are simple, flexible and secure switches ideal for out-of-the-wiring-closet and critical Internet of Things (IoT) deployments. Cisco® Catalyst® 1000 operate on Cisco IOS® Software and support simple device management and network management via a Command-Line Interface (CLI) as well as an on-box web UI. These switches deliver enhanced network security, network reliability, and operational efficiency for small organizations.
The Cisco Catalyst 1000 Series Switches provides these features
:
* 8, 16, 24, or 48 Gigabit Ethernet data or PoE+ ports with line-rate forwarding
* 2 or 4 fixed 1 Gigabit Ethernet Small Form-Factor Pluggable (SFP)/RJ 45 Combo uplinks or 4 fixed 0 Gigabit Ethernet Enhanced SFP (SFP+) uplinks
* Perpetual PoE+ support with a power budget of up to 740W
* CLI and/or intuitive web UI manageability options
* Network monitoring through sampled flow (sFlow)
* Security with 802.1X support for connected devices, Switched Port Analyzer (SPAN), and Bridge Protocol Data Unit (BPDU) Guard
* Compact fanless models available with a depth of less than 13 inches (33 cm)
*Device management support with over-the-air access via Bluetooth, Simple Network Management Protocol (SNMP), RJ-45, or USB console access
* Reliability with a higher Mean Time Between Failures (MTBF) and an enhanced limited lifetime warranty support(E-LLW)
* 2 or 4 fixed 1 Gigabit Ethernet Small Form-Factor Pluggable (SFP)/RJ 45 Combo uplinks or 4 fixed 0 Gigabit Ethernet Enhanced SFP (SFP+) uplinks
* Perpetual PoE+ support with a power budget of up to 740W
* CLI and/or intuitive web UI manageability options
* Network monitoring through sampled flow (sFlow)
* Security with 802.1X support for connected devices, Switched Port Analyzer (SPAN), and Bridge Protocol Data Unit (BPDU) Guard
* Compact fanless models available with a depth of less than 13 inches (33 cm)
*Device management support with over-the-air access via Bluetooth, Simple Network Management Protocol (SNMP), RJ-45, or USB console access
* Reliability with a higher Mean Time Between Failures (MTBF) and an enhanced limited lifetime warranty support(E-LLW)
|
C1000-24P-4G-L Specification
|
|
|
|
Description
|
24x 10/100/1000 Ethernet PoE+ ports and 195W PoE budget, 4x 1G SFP uplinks
|
|
|
Gigabit Ethernet ports
|
24
|
|
|
Uplink interfaces
|
4 SFP
|
|
|
PoE+power budget
|
195W
|
|
|
Fanless
|
Y
|
|
|
Dimensions (WxDxH in inches)
|
17.5 x 11.76 x 1.73
|
|
|
Console ports
|
|
|
|
RJ-45 Ethernet
|
1
|
|
|
USB mini-B
|
1
|
|
|
USB-A port for storage and Bluetooth console
|
1
|
|
|
Memory and processor
|
|
|
|
CPU
|
ARM v7 800 MHz
|
|
|
DRAM
|
512 MB
|
|
|
Flash memory
|
256 MB
|
|
|
Performance
|
|
|
|
Forwarding bandwidth
|
28 Gbps
|
|
|
Switching bandwidth
|
56 Gbps
|
|
|
Forwarding rate(64—byte L3 packets)
|
41.67 Mpps
|
|
|
Unicast MAC addresses
|
16000
|
|
|
IPv4 unicast direct routes
|
542
|
|
|
IPv4 unicast indirect routes
|
256
|
|
|
IPv6 unicast direct routes
|
414
|
|
|
IPv6 unicast indirect routes
|
128
|
|
|
IPv4 static routes
|
16
|
|
|
IPv6 static routes
|
16
|
|
|
IPv4 multicast routes and IGMP groups
|
1024
|
|
|
IPv6 multicast groups
|
1024
|
|
|
IPv4/MAC security ACEs
|
600
|
|
|
IPv6 security ACEs
|
600
|
|
|
Maximum active VLANs
|
256
|
|
|
VLAN IDs available
|
4094
|
|
|
Maximum STP instances
|
64
|
|
|
Maximum SPAN sessions
|
4
|
|
|
MTU-L3 packet
|
9198 bytes
|
|
|
Jumbo Ethernet frame
|
10,240 bytes
|
|
|
Dying Gasp
|
Yes
|
|
|
MTBF in hours (data)
|
2,026,793
|
|
|
MTBF in hours (PoE)
|
698,220
|
|
|
MTBF in hours (Full PoE)
|
698,220
|
|
