Oriental Motor Speed Controller

ORIENTAL MOTOR

Speed Control Motors

For applications whre variable speeds are necessary, typically an AC motor with an Inverter or brush motors are used.  Brushless DC motors are an advanced option due to their wide speed range, low heat and maintenance-free operation.    Stepper Motors offer high torque and smooth low speed operation.

Speed is typically controlled by manual operation on the dricer or by an extemal switch, or with an extermal 0-10 VDC.     Speed control systems typexally utilize gearheads to increase output torque.    Gear types range from spur, worm or helical / hypoid depending on torque demands and budgets.

Mounting configurations vary to depending on space constraints or design of the application.

	Brushless DC Gear Motor and Driver	AC Speed Control Systems	Three-Phase Gear Motor and Inverter
Features	Compact Size Multiple Geared Motor Options High Efficiency / Lower Operationg Temperature Torque Control	High Torque Type SCM Series Motors Vertical Operation Plug & Play	Multiple Geared Motor Options Auto-Tuning / Dynamic Torque Vector Control Automatic Torque Boost / Slip Compensation RS-485 Networking
Composition	Permanent Magnet DC Motor with Hall Effector Sensor or Encoder Feedback + Dedicated Driver	Single-Phase AC Motor with Tachogenerator Feedback + Dedicated Controller	Three-Phase Induction Motor + General-purpose Inverter
Output Power	15 W (1/50 HP) up to 400 W (1/2 HP)	6 W (1/125 HP) up to 90 W (1/8 HP)	90 W (1/8 JP) up to 3 HP
System Type	Closed-loop Control	Closed-loop Control	Open-loop Control
Speed Setting Methods	Digital  / Analog (up to 16 speeds)	Digital / Analog (up to 4 speeds)	Digital / Analog (up to 16 speeds)
Rotation Speed (speed ratio)	80 - 4000 r/min (1:50)	90-1600 r/min (1:18)	90-3600 r/min (1:40)
Efficiency / Energy Saving	High effeciency with permanent magnet motor	Low Efficiency with AC Motors	Low Efficiency with AC Motors
Speed Regulation (Load)	±0.2 ~ ±0.05%	±1%	-3 ~ -15%
