Fuhuide A107 Stainless Steel electrode E308-15 stainless steel welding electrode

Fuhuide A107 Stainless Steel electrode E308-15 stainless steel welding electrode

FOB Reference Price: Get Latest Price

≥1 Kilograms

US $2.8

≥1500 Kilograms

US $2.5

≥50000 Kilograms

US $1

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Place of Origin:: Hebei, China

Brand Name:: Fuhuide

Model Number:: A107

Operating Current:: DC AC

Application:: welding the corrosion resistant stainless

Usages:: welding the corrosion resistant stainless steel structure

Product Name:: Electrode Welding 2.6mm

keyword:: welding electrode brand

Model:: a107 e308-15

Type:: Titanium calcium type coating

Quick Details

Material:: Stainless steel

Welding Current:: 40-230A

Operating Temperature:: Standard Temperature

Place of Origin:: Hebei, China

Brand Name:: Fuhuide

Model Number:: A107

Operating Current:: DC AC

Application:: welding the corrosion resistant stainless

Usages:: welding the corrosion resistant stainless steel structure

Product Name:: Electrode Welding 2.6mm

keyword:: welding electrode brand

Model:: a107 e308-15

Type:: Titanium calcium type coating

The product description

Description：

A107 e308-15 is a kind of Titanium calcium type coating Cr19Ni10 stainless steel electrode. The deposited metal has good mechanical properties and intergranular corrosion resistance. It has good welding performance and porosity resistance. Heat resistance coating and crack resistance. AC/DC both can be applied.

Application

Used for welding the corrosion resistant stainless steel structure, such as 06Cr19Ni10 and 06Cr18Ni11Ti and their working temperature should be below 300℃

Chemical Composition (%)

*Chemical Composition*	C	Mn	Si	S	P	Cr	Ni	Mo	Cu
*Guarantee Value*	*≤0.08*	*0.50~2.50*	*≤1.00*	*≤0.030*	*≤0.040*	*18.0~21.0*	*9.0~11.0*	*≤0.75*	*≤0.75*
*General Result*	*0.038*	*1.35*	*0.68*	*0.008*	*0.022*	*19.75*	*9.60*	*0.064*	*0.10*

Mechanical Properties of Deposited Metal

*Test Item*	*Rm(N/mm2)*	*A (%)*
*Guarantee Value*	*≥550*	*≥30*
*General Result*	*590*	45

Reference Current (AC DC+)

*Diameter (mm)*	*φ2.0*	*φ2.5*	*φ3.2*	*φ4.0*	*φ5.0*
*Welding Current (Amps)*	*40~80*	*50~100*	*70~130*	*100~160*	*140~200*
